Harman Kardon AVR 360

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
...4 CN57 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) 1 EA
...4 C706 CCEA1EH222E CAP , ELECT 2200UF 25V 1 EA
Level
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
..3 COP12169F AVR360 USB IPOD PCB ASS'
Y
1E
A
....6 C101 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C105 CCUS1H180JA CAP , CHIP(18PF/50V) 18PF 50V J 1 EA
....6 C106 CCUS1H200JA CAP , CHIP (20PF) 1EA
....6 C110 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C112 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C113 CCUS1H150JA CAP , CHIP(15PF/50V) 15PF 50V J 1 EA
....6 C114 CCUS1H150JA CAP , CHIP(15PF/50V) 15PF 50V J 1 EA
....6 C115 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C123 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C134 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C135 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....6 C136 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C137 CCUS1H270JA CAP , CHIP 27PF 50V J 1 EA
....6 C139 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C149 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C150 CCEC1CRV471T CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 1 EA
....6 C152 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C154 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C161 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C169 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C172 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C175 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C178 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C181 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C182 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C185 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C186 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C187 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C188 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C195 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
....6 C197 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
....6 C209 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
....6 C213 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C214 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C216 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C217 CCUS1A105KC CAP , CHIP 1UF 10V K 1 EA
....6 C218 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....6 C228 CCUS1H330JA CAP , CHIP 33PF 50V J 1 EA
....6 C229 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....6 D101 CVD1SS355T DIODE , CHIP 1EA
....6 D103 CVD1SS355T DIODE , CHIP 1EA
....6 D921 CVD1SS355T DIODE , CHIP 1EA
....6 IC204 CVITMP92FD28FG I.C , USB DECODER FLASH
(
100PIN, QFP
)
TO
S
TMP92FD28DFG, FLASH 1 EA
....6 IC207 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
....6 IC208 HVIRH5VT28C I.C , RESET (RICOH) 1 EA
....6 IC209 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
....6 IC211 CVINJM2505AFTE1 I.C , VIDEO AMP
(
4.5~9.0V , 200MW , MTP5
)
J
R
NJM2505AF-TE1 , JRC 1 EA
....6 IC212 CVINJM2505AFTE1 I.C , VIDEO AMP
(
4.5~9.0V , 200MW , MTP5
)
J
R
NJM2505AF-TE1 , JRC 1 EA
....6 IC213 CVINJM2505AFTE1 I.C , VIDEO AMP
(
4.5~9.0V , 200MW , MTP5
)
J
R
NJM2505AF-TE1 , JRC 1 EA
....6 IC214 HVINJM2581MTE1 I.C (JRC) 1EA
....6 IC216 CVITL072CDR I.C , OP AMP/SOP/8P (TI) 1 EA
....6 IC217 HVINJM2068MDTE1 I.C , OP AMP (JRC) NJM2068MD-TE1 1 EA
....6 IC220 HVI74LCX32TTR I.C , OR-GATE (ST) 74LCX32 1 EA
....6 L101 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
....6 L102 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....6 L105 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
....6 L106 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
....6 Q102 HVTKRC102S T.R , CHIP KRC102S 1 EA
....6 Q103 HVTKRC107S T.R , CHIP 1EA
....6 Q104 HVTKRA107S TR, CHIP 1EA
....6 Q105 HVTKRA107S TR, CHIP 1EA
....6 Q106 HVTKRA107S TR, CHIP 1EA
....6 Q107 HVTKRC107S T.R , CHIP 1EA
....6 R107 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R108 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R109 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R110 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R111 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R117 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R118 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R119 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R120 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R121 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R122 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R123 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....6 R179 CRJ10DJ4R7T RES , CHIP (4.7 OHM) 1608 SIZE 1 EA
....6 R182 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R183 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
HDMI PCB ASS
Y
USB IPOD PCB ASS
Y
