Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....6 R185 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R186 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R188 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R189 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R192 CRJ10DJ222T RES , CHIP (2.2K OHM) 1608 SIZE 1 EA
....6 R193 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R195 CRJ10DJ221T RES , CHIP (220 OHM) 1608 SIZE 1 EA
....6 R196 CRJ10DJ221T RES , CHIP (220 OHM) 1608 SIZE 1 EA
....6 R201 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R202 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R203 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R204 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R205 CRJ10DF5101T RES. CHIP (5.1K 1%) 1608 SIZE 1 EA
....6 R206 CRJ10DF5101T RES. CHIP (5.1K 1%) 1608 SIZE 1 EA
....6 R207 CRJ10DF1002T RES , CHIP 1% 10K /1/10W/F 1 EA
....6 R208 CRJ10DF1002T RES , CHIP 1% 10K /1/10W/F 1 EA
....6 R209 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R210 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
....6 R213 CRJ10DF1001T RES , CHIP 1% 1K/1/10W/F 1 EA
....6 R214 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R215 CRJ10DF4992T RES , CHIP(49.9K, 1608, 1%) 1 EA
....6 R222 CRJ10DJ220T RES , CHIP (22 OHM) 1608 SIZE 1 EA
....6 R223 CRJ10DJ220T RES , CHIP (22 OHM) 1608 SIZE 1 EA
....6 R224 CRJ10DJ220T RES , CHIP (22 OHM) 1608 SIZE 1 EA
....6 R225 CRJ10DJ220T RES , CHIP (22 OHM) 1608 SIZE 1 EA
....6 R232 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R233 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R234 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R235 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R236 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R237 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R238 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....6 R240 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R242 CRJ10DJ222T RES , CHIP (2.2K OHM) 1608 SIZE 1 EA
....6 R243 CRJ10DJ222T RES , CHIP (2.2K OHM) 1608 SIZE 1 EA
....6 R244 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....6 R245 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....6 R246 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....6 R247 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R248 CRJ10DJ221T RES , CHIP (220 OHM) 1608 SIZE 1 EA
....6 R249 CRJ10DJ221T RES , CHIP (220 OHM) 1608 SIZE 1 EA
....6 R250 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R251 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....6 R260 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....6 R297 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R298 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R299 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R300 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R301 CRJ10DF1001T RES , CHIP 1% 1K/1/10W/F 1 EA
....6 R302 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....6 R303 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R304 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R305 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....6 R306 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R308 CRJ10DF1001T RES , CHIP 1% 1K/1/10W/F 1 EA
....6 R309 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....6 R310 CRJ10DJ221T RES , CHIP (220 OHM) 1608 SIZE 1 EA
....6 R352 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....6 R354 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....6 R355 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....6 R500 CRJ10DJ4R7T RES , CHIP (4.7 OHM) 1608 SIZE 1 EA
....5 C104 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C109 CCEA1CH221T CAP , ELECT 220UF 16V 1 EA
....5 C111 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
....5 C138 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C151 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C153 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C157 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
....5 C163 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C164 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C165 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C166 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C167 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C168 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C170 CCEA1CH470T CAP , ELECT 47UF 16V 1 EA
....5 C171 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C173 CCEA1CH470T CAP , ELECT 47UF 16V 1 EA
....5 C174 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C176 CCEA1CH470T CAP , ELECT 47UF 16V 1 EA
....5 C177 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C179 CCEA1CH470T CAP , ELECT 47UF 16V 1 EA
....5 C189 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C190 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C196 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
USB IPOD PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 44 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
