Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 C198 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
....5 C215 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
....5 IC223 HVIKA78L05AZT REGULATOR, +5V KA78LXXAZTA 1 EA
...4 CQB1D022 A-ROHS/LABEL,SERIAL 1 EA
...4 BK11 CMD1A569 BRACKET , PCB 1EA
...4 BK12 CMD1A569 BRACKET , PCB 1EA
...4 BN50 CJP05GA19ZY WAFER , STRAIGHT 1 EA
...4 BN55 CJP26GA240ZB PIN HEADER (26P, 2.54mm), STRAIGHT TYPE 1 EA
...4 CN51 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 1 EA
...4 CN58 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 1 EA
...4 CN81 CJP44GA241ZB FEMALE HEADER (44P,2.54mm) , DIP/STRAIGHT 1 EA
...4 IC201 BVIKP1010B IC, PHOTO COUPLER (COSMO) 1 EA
...4 IC202 BVIKP1010B IC, PHOTO COUPLER (COSMO) 1 EA
...4 IC203 HVIKIA78R05PI REGULATOR (5V OUTPUT LOW DROP) KIA78R05PI 1 EA
...4 IC215 CVITMP86F409NG I.C , IPOD UART BUFFER (TOSHIBA) 1 EA
...4 JK12 CJJ2D008Z JACK , STEREO 1EA
...4 JK13 CJJ2D008Z JACK , STEREO 1EA
...4 JK14 CJJ2D008Z JACK , STEREO 1EA
...4 JK17 CJJ9L016Z JACK , IPOD CONNECTOR (36PIN) SCSI36P 1 EA
...4 X101 COX09000E150C CRYSTAL(9MHZ) 1EA
...4 X103 HOX12000E200C 12MHz CRYSTAL 1EA
...4 X104 HOX00032K120I CRYSTAL , 32.768KHZ TUNING FORK 1 EA
USB IPOD PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 45 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
