Ver.4
NJM2505A
■
■■
■ EQUIVALENT CIRCUIT
Pin.No Symbol Inside Equivalent Circuit Voitage
1 Vout
0.92V
2 GND -
-
3 V
+
- -
4 Vin
1.67V
5 VGND
1.67V
31k
30k
240
80
AVR3600 harman/kardon
116
