Harman Kardon AVR 3600 Service Manual

74ACT04
2/8
INPUT AND OUTPUT EQUIVALENT CIRCUIT PIN DESCRIPTION
TRUTH TABLE
ABSOLUTE MAXIMUM RATINGS
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is
not implied.
RECOMMENDED OPERATING CONDITIONS
1) V
IN
from 0.8V to 2.0V
PIN No SYMBOL NAME AND FUNCTION
1, 3, 5, 9, 11,
13
1A to 6A Data Inputs
2, 4, 6, 8, 10,
12
1Y to 6Y Data Outputs
7 GND Ground (0V)
14
V
CC
Positive Supply Voltage
AY
LH
HL
Symbol Parameter Value Unit
V
CC
Supply Voltage
-0.5 to +7 V
V
I
DC Input Voltage -0.5 to V
CC
+ 0.5
V
V
O
DC Output Voltage -0.5 to V
CC
+ 0.5
V
I
IK
DC Input Diode Current
± 20 mA
I
OK
DC Output Diode Current
± 20 mA
I
O
DC Output Current
± 50 mA
I
CC
or I
GND
DC V
CC
or Ground Current
± 200 mA
T
stg
Storage Temperature
-65 to +150 °C
T
L
Lead Temperature (10 sec)
300 °C
Symbol Parameter Value Unit
V
CC
Supply Voltage
4.5 to 5.5 V
V
I
Input Voltage 0 to V
CC
V
V
O
Output Voltage 0 to V
CC
V
T
op
Operating Temperature
-55 to 125 °C
dt/dv
Input Rise and Fall Time V
CC
= 4.5 to 5.5V (note 1)
8 ns/V
AVR3600 harman/kardon
203

Harman Kardon AVR 3600 Specifications

General

Brand	Harman Kardon
Model	AVR 3600
Category	Receiver
Language	English
