Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
MAIN PCB ASS'Y COP12170D
C819 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C820 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C851 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C852 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C853 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C854 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C855 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C856 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C857 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C905 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C907 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C908 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C911 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
C912 CCEA1CH221T CAP , ELECT 220UF 16V 1 EA
C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C918 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C919 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C924 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
C925 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
C932 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C933 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
C934 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z 1 EA
C936 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
C939 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C940 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C948 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C950 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C974 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C975 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C977 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C991 CCEA1HH1R0T CAP , ELECT 1UF 50V 1 EA
C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C994 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C996 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C999 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C631 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C632 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C633 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C634 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C635 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C636 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C637 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C638 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C639 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C640 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C807 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C808 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C809 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C810 CCEA1JH221E CAP , ELECT 220UF 63V 1 EA
C904 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV 1 EA
