Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
MAIN PCB ASS'Y COP12170D
Q544 HVTKTC3198YT
TRANSISTOR NPN
KTC3198Y 1 EA
Q545 HVTKTC3198YT
TRANSISTOR NPN
KTC3198Y 1 EA
Q556 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q557 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q558 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q559 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q560 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q561 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q562 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q563 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q564 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q565 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q601 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q602 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q603 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q604 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q605 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q681 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q682 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q683 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q684 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q685 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q801 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q802 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q812 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q813 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q814 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q815 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q816 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q817 HVTKTA1268GRT
TRANSISTOR PNP
KTA1268GR 1 EA
Q818 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q819 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q820 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q821 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q822 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q823 HVTKTC3200GRT
TRANSISTOR NPN
KTC3200GR 1 EA
Q824 HVTKTC3198YT
TRANSISTOR NPN
KTC3198Y 1 EA
Q825 HVTKTC3198YT
TRANSISTOR NPN
KTC3198Y 1 EA
Q901 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q911 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q912 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q913 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q914 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q915 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q916 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q917 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q918 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q938 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q939 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q941 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q942 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q943 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
Q960 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q961 HVTKTA1024YT
TRANSISTOR PNP
KTA1024-Y-AT/P 1 EA
Q652 CVT2SB1560P43M TRANSISTOR , POWER (MICA 43 TYPE) PNP 2SB1560P43M 1 EA
Q653 CVT2SB1560P43M TRANSISTOR , POWER (MICA 43 TYPE) PNP 2SB1560P43M 1 EA
Q654 CVT2SB1560P43M TRANSISTOR , POWER (MICA 43 TYPE) PNP 2SB1560P43M 1 EA
Q655 CVT2SB1560P43M TRANSISTOR , POWER (MICA 43 TYPE) PNP 2SB1560P43M 1 EA
Q657 CVT2SD2390P43M TRANSISTOR , POWER (MICA 43 TYPE) NPN 2SD2390P 1 EA
Q658 CVT2SD2390P43M TRANSISTOR , POWER (MICA 43 TYPE) NPN 2SD2390P 1 EA
Q659 CVT2SD2390P43M TRANSISTOR , POWER (MICA 43 TYPE) NPN 2SD2390P 1 EA
Q660 CVT2SD2390P43M TRANSISTOR , POWER (MICA 43 TYPE) NPN 2SD2390P 1 EA
Q661 CVT2SB1560P43M TRANSISTOR , POWER (MICA 43 TYPE) PNP 2SB1560P43M 1 EA
Q670 CVT2SD2390P43M TRANSISTOR , POWER (MICA 43 TYPE) NPN 2SD2390P 1 EA
