Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
POWER PCB ASS'Y CIP12172D
ET04 CMD1A736 BRACKET , PCB 1EA
JK75 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
JK76 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
JK77 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
JK99 CJJ9B001Z
JACK, DC POWER (3PIN / 1.GND 2.OPEN 3.DC POWER) DS-201S-3 1 EA
VIDEO IN/OUT PCB ASS'YS COP12175D
Capacitors
C401 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C404 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C411 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C421 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C451 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C491 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C601 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C602 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C603 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C604 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C605 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C606 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C611 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C613 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C615 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C621 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C623 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C625 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
Resistors
R401 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R411 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R421 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R451 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R491 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R601 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R603 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R605 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R611 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R612 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R613 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R621 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R622 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R623 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
Miscellaneous
BN56 CJP16GB142ZB PIN , HEADER (16PIN, 2.54mm, ANGLE) 1 EA
BN57 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
JK40 CJJ4N043Z JACK , BOARD RCA-215A-02 1 EA
JK41 CJJ4N043Z JACK , BOARD RCA-215A-02 1 EA
JK42 CJJ4R045Z JACK , BOARD SILVER PLATE 1 EA
JK43 CJJ4S030Z JACK , BOARD 3P,G/B/R,SILVER 1 EA
JK44 CJJ4M049Y JACK , RCA(1P,RCA-115A-05) RCA-115A-05 1 EA
INPUT PCB ASS'Y COP12177D
Capacitors
C203 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C204 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C205 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C206 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
AVR3600 harman/kardon
56
