8 FRONT-PANEL INFORMATION DISPLAY
L Time Indicator:This indicator lights in con-
junction with one of the time indicators OPQ
to show which of the time status modes is
active.
M Remaining-Time Indicator:This indicator
lights when the Information Display K shows
the time remaining on a disc.
N Total Time:This indicator lights when the
Information Display K shows the total time of
all tracks on a disc.
O Track Time:This indicator lights when the
Information Display K shows the running time
of the individual track being played.
P R/RW Indicator:This indicator shows which
type of recordable disc is present in the Record
Deck %.When a CD-R disc is present, only the
R is lit.The RW lights when an erasable CD-RW
disc is in use.
Q Play/Pause Indicator: These indicators
show the status of the individual CD Decks.The
››
›› lights when the CD is playing, and the
››
››
±±
lights when the unit is in a Pause mode.
R Sample-Rate Converter:This indicator
lights when the Sample-Rate Converter is in use
to change the digital sample rate when the
incoming signal is not the standard 44.1kHz
used by standard CDs.This is an automatic func-
tion and does not require any user intervention.
S CD Indicator:This indicator lights when a
standard CD is playing in either deck 3 or %.
T Record Indicator: This indicator lights
when the unit is making a recording and flashes
during the preparations for recording.
U Finalize Indicator:This indicator lights
when the unit is in the Finalization process,
which is required before a CD-R disc may be
played on a standard CD machine. See page 22
for more information on Finalization.
V Erase Indicator: This indicator lights when
a CD-RW disc is being erased.Note that only
CD-RW discs may be erased;it is not possible to
erase a CD-R disc.See page 22 for more infor-
mation on erasing discs.
W Auto Indicator:This indicator lights when
the automatic method of incrementing tracks is
selected for a recording session.
X Analog Indicator:This indicator lights
when an analog source is being recorded.
See page 20 for more information on source
selection.
Y Digital Indicator:This indicator lights when
an digital source is being recorded. See page 20
for more information on source selection.
