Harman Kardon SUB-TS18 Service Manual

Part number Description Qty Reference Designator
PREAMP PCB
Miscellaneous
162-50122004-e drop-out line 120mm RED/WHT 2PIN (RoHS) 1 D209
162-5014d008-e WIRE 2468#26AWG RED/WHT length 140mm (RoHS) 1 P1-P2
162-a016d001-e mixed wire UL1007 160/80mm#26 (RoHS) 1 W202
174-0rca313v-e RCA JACK RCA-313G V/R/W (RoHS) 1 JK201
174-20810360g-e jack SPK JK BP 8PIN (RoHS) SH0810360G US1.35 1 JK202
174-6ej3556agp-e PHONE JACK EJ3556A-GP (RoHS) 1 JK203
175-1b08v01-e WIRE CONNECTOR & BASE 8 PIN PITCH=2.0mm(RoHS) 1 W202
175-1c07v01-e WIRE CONNECTOR & BASE 7PIN PITCH=2.5mm (RoHS) 1 M201
180-tms7210v-e SWITCH SLIDE 6PIN MS7210V (RoHS) 3 SW201,SW202,SW203
362-FE-00041-0LAE PCB support 11.75*8.5*12.5H (RoHS) 2
MAIN PCB
Resistors
110-14103j26-e RESISTOR 10K 1/4W ±5% CF 26mm (RoHS) 3 R503,R504,R510
110-14222j26-e RESISTOR 2.2K 1/4W ±5% CF 26mm (RoHS) 1 R511
110-14432j26-e RESISTOR 4.3K 1/4W ±5% CF 26mm (RoHS) 1 R506
110-14472j26-e RESISTOR 4.7K 1/4W ±5% CF 26mm (RoHS) 1 R505
110-16102j26-e RESISTOR 1K 1/6W ±5% CF 26mm (RoHS) 1 R153
110-16103j26-e RESISTOR 10K 1/6W ±5% CF 26mm (RoHS) 10
R128,R130,R149,R150,R305,R306,R308,R311,R314,R
319
110-16104j26-e RESISTOR 100K 1/6W ±5% CF 26mm (RoHS) 3 R122,R126,R307
110-16153j26-e RESISTOR 15K 1/6W ±5% CF 26mm (RoHS) 1 R107
110-16182j26-e RESISTOR 1.8K 1/6W ±5% CF 26mm (RoHS) 1 R145
110-16203j26-e RESISTOR 20K 1/6W ±5% CF 26mm (RoHS) 1 R309
110-16221j26-e RESISTOR 220Ω 1/6W ±5% CF 26mm (RoHS) 1 R144
110-16222j26-e RESISTOR 2.2K 1/6W ±5% CF 26mm (RoHS) 1 R102
110-16223j26-e RESISTOR 22K 1/6W ±5% CF 26mm (RoHS) 1 R316
110-16333j26-e RESISTOR 33K 1/6W ±5% CF 26mm (RoHS) 1 R310
110-16393j26-e RESISTOR 39K 1/6W ±5% CF 26mm (RoHS) 1 R151
110-16434j26-e RESISTOR 430K 1/6W ±5% CF 26mm (RoHS) 1 R312
110-16473j26-e RESISTOR 47K 1/6W ±5% CF 26mm (RoHS) 2 R106,R129
110-16474j26-e RESISTOR 470K 1/6W ±5% CF 26mm (RoHS) 1 R127
110-16562j26-e RESISTOR 5.6K 1/6W ±5% CF 26mm (RoHS) 1 R152
110-16621j26-e RESISTOR 620Ω 1/6W ±5% CF 26mm (RoHS) 1 R160
110-16751j26-e RESISTOR 750Ω 1/6W ±5% CF 26mm (RoHS) 1 R315
110-16755j26-e RESISTOR 7.5M 1/6W ±5% CF 26mm (RoHS) 1 R313
116-161002f26-e metal film RESISTOR 10K 1/6W ±1% MF 26mm (RoHS) 2 R301,R303
116-161202f26-e metal film RESISTOR 12.0K 1/6W ±1% MF 26mm (RoHS) 1 R302
116-162200f26-e metal film RESISTOR 220Ω 1/6W ±1% MF 26mm (RoHS) 1 R317
116-162202f26-e metal film RESISTOR 22.0K 1/6W ±1% MF 26mm (RoHS) 1 R318
110-20332jk3-e RESISTOR 3.3K 2W ±5% standing short crus 7.5m (RoHS) 1 R134
113-50s68j00-e cement RESISTOR 0.068Ω 5W ±5% prone long crus (RoHS) 1 R147
116-201001jk3x-e oxide film RESISTOR 1.00K 2W ±5% 7.5mm (RoHS) 1 R148
116-304700jk2x-e oxide film RESISTOR 470Ω 3W ±5% 10mm (RoHS) 2 R501,R502
Capacitors
130-3f104z503-e DISC CAPACITOR 0.1U 50V +80/-20% (RoHS) 6 C107,C117,C122,C144,C320,C322
130-sl101k503-e DISC CAPACITOR 100P 50V SL ±10% (RoHS) 3 C302,C303,C306
132-103j503-e MYLAR CAPACITOR 0.01uF 50V ±5% (RoHS) 2 C305,C317
132-103ja03-e MYLAR CAPACITOR 0.01uf 100V ±5% (RoHS) 2 C103,C104
132-104ja03-e MYLAR CAPACITOR 0.1UF 100V ±5% (RoHS) 3 C123,C503,C504
132-273ja03-e MYLAR CAPACITOR 0.027UF 100V ±5% (RoHS) 1 C143
135-3106m50-e ELECTROLYTIC CAP. 10uF 50V ±20% (RoHS) 2 C319,C321
135-3107m10-e ELECTROLYTIC CAP. 100U 10V ±20% (RoHS) 2 C114,C115
135-3107m35-e ELECTROLYTIC CAP. 100U 35V ±20% (RoHS) 2 C507,C508
135-3225m50-e ELECTROLYTIC CAP. 2.2U 50V ±20% (RoHS) 1 C509
135-3226m16-e ELECTROLYTIC CAP. 22U 16V ±20% (RoHS) 1 C304
135-3226m50-e ELECTROLYTIC CAP. 22U 50V ±20% (RoHS) 2 C505,C506
135-3227m16-e ELECTROLYTIC CAP. 220U 16V ±20% (RoHS) 1 C118
135-3476m16-e ELECTROLYTIC CAP. 47U 16V ±20% (RoHS) 1 C318
21
SUB-TS18 harman/kardon
