Harman Kardon SUB-TS18 Service Manual

Part number Description Qty Reference Designator
MAIN PCB
138-5478m80-e LARGE ELECTROLYTIC CAP. 4700uF 80V ±20% 85 ℃ 2 C501,C502
132-103kd00-e MYLAR CAPACITOR 0.01U 400V +/-10% long crus (RoHS) 1 C500
Semiconductors
192-027c1815gr-e TRANSISTOR 2SC1815GR NPN TOSHIBA(RoHS) 5 Q108,Q109,Q113,Q301,Q302
192-027c2235y-e TRANSISTOR 2SC2235Y NPN TOSHIBA (RoHS) 1 Q111
192-028a1015gr-e TRANSISTOR 2SA1015GR PNP TOSHIBA(RoHS) 3 Q101,Q107,Q112
192-1572n5551-e *TRANSISTOR FSC 2N5551 NPN (RoHS) 2 Q114,Q115
192-1582n5401-e
TRANSISTOR FSC 2N5401 AI-PNP 350V 500mA TO-92
(RoHS)
1 Q503
197-631n4148-e DIODE 500mW 75V 1N4148 Panjit (RoHS) 7 D102,D103,D104,D105,D143,D301,D302
199-65000623g-e ZENER DIODE GDZJ6.2B 500mW 6.2V 26mm 2% (RoHS) 1 D101
199-65001603g-e ZENER DIODE GDZJ16C 500mW 16V 26mm 2% (RoHS) 1 D502
190-16tl074cn-e I.C TL074CN ST QUAD OP-AMP 1 U301
192-161tip31c-e TRANSISTOR TIP31C NPN SGS (RoHS) 1 Q501
192-162tip32c-e TRANSISTOR TIP32C PNP SGS (RoHS) 1 Q502
197-00kbu606g-e bridge rectifier 6A 800V KBU606G (RoHS) 1 D501
197-141n4004-e *DIODE 1N4004 shaping short crus (RoHS) 2 D110,D504
Miscellaneous
109-1ttc802j0-e thermistor TTC-802(JS) NTC long crus (RoHS) 1 TH1
120-1000003-e inductor 10W AI YT-C3104-005 1CRHW 354708LTB (RoHS) 2 FB1,FB2
162-50129001-e CABLE ASS'Y drop-out line 120mm AWG28 WHT (RoHS) 1 W201
171-urwh124d-e relay RWH-SH-124D (1600 ohm) (RoHS) 1 RL1
175-1d02v01-e WIRE CONNECTOR & BASE 2PIN PITCH=3.96mm (RoHS) 1 M100
175-1d03v01-e
WIRE CONNECTOR & BASE 3 PIN PITCH=3.96mm JST-VH
take off the middle PIN
1 M500
CLASS D ASS'Y PCB (Replacment of entire module is recommended, part# 051-B00012A-E).
Resistors
118-12061001j-e SMD RESISTOR 1.00K 1206 5% (RoHS) 4 R2,R11,R29,R30
118-12061002j-e SMD RESISTOR 10.0K 1206 5% (RoHS) 3 R7,R9,R25
118-120610r0j-e SMD RESISTOR 10.0Ω 1206 5% (RoHS) 2 R22,R23
118-12061201j-e SMD RESISTOR 1.20K 1206 5% (RoHS) 16
R31,R32,R33,R34,R35,R36,R37,R38,R39,R40,R41,
R42,R43,R44,R45,R46
118-12062002j-e SMD RESISTOR 20.0K 1206 5% (RoHS) 1 R26
118-12062201j-e SMD RESISTOR 2.20K 1206 5% (RoHS) 3 R6,R13,R16
118-12062701j-e SMD RESISTOR 2.70K 1206 5% (RoHS) 1 R10
118-12063000j-e SMD RESISTOR 300.0Ω 1206 5% (RoHS) 1 R24
118-12063301j-e SMD RESISTOR 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28
118-12063902j-e SMD RESISTOR 39.0K 1206 5% (RoHS) 1 R3
118-12064700j-e SMD RESISTOR 470Ω 1206 5% (RoHS) 1 R8
118-12064701j-e SMD RESISTOR 4.70K 1206 5% (RoHS) 3 R1,R5,R12
118-12064702j-e SMD RESISTOR 47.0K 1206 5% (RoHS) 1 R17
118-12064704j-e SMD RESISTOR 4.70M 1206 5% (RoHS) 1 R4
118-120647r0j-e SMD RESISTOR 47.0Ω 1206 5% (RoHS) 2 R20,R21
Capacitors
141-c0101k50-e SMD CAPACITOR 100pF 50V 10% 1206 NP0 (RoHS) 1 C4
141-c0220k50-e SMD CAPACITOR 22pF 50V 10% 1206 SMT NPO (RoHS) 1 C5
141-c0561k50-e SMD CAPACITOR 560pF 50V 10% 1206 NPO (RoHS) 1 C6
141-c5104m50-e SMD CAPACITOR 1206 Y5V 0.1uF 50V ±20% (RoHS) 8 C2,C3,C7,C8,C9,C10,C11,C15
141-c7223k50-e SMD CAPACITOR 0.022uF 50V 10% 1206 X7R (RoHS) 1 C13
141-d7104ka0-e SMD CAPACITOR 0.1uF 100V 10% 1210 X7R (RoHS) 1 C12
141-d7104kb5-e SMD CAPACITOR 0.1uF 250V 10% 1210 X7R (RoHS) 5 C1,C18,C19,C20,C14
Semiconductors
190-16tl072dts-e *SMD I.C. TL072CDT Dual Op-Amp SGS THOMSON (RoHS) 1 IC1
192-09124126qs-e SMD TRANSISTOR 2SC2412K-T146Q/R ROHM (RoHS) 3 Q1,Q4,Q5
22
SUB-TS18 harman/kardon
