Part number Description Qty Reference Designator
CLASS D ASS'Y PCB
192-09139066rs-e SMD TRANSISTOR 2SC3906K-T146R ROHM (RoHS) 2 Q2,Q8
192-09210376qs-e SMD TRANSISTOR 2SA1037K-T146Q/R ROHM (RoHS) 2 Q7,Q9
192-09215146rs-e SMD TRANSISTOR 2SA1514K-T146R ROHM (RoHS) 2 Q3,Q6
197-03rls4148s-e *SMD DIODE RLS4148-TE11 ROHM (RoHS) 6 D1,D2,D3,D4,D5,D6
199-15000563s-e SMD ZENER 5.6V 5% PHILIPS BZX84-C5V6 (RoHS) 2 Z1,Z2
199-1500120s-e SMD ZENER 12V 5% PHILIPS BZX84-C12 (RoHS) 2 Z5,Z6
199-15001503s-e SMD ZENER 15V 5% PHILIPS BZX84-C15 (RoHS) 2 Z3,Z4
192-233f640n-e TRANSISTOR IRF640N INTERNATIONAL (RoHS) 1 Q11
192-232irf9640-e FET IRF9640 IR P-CH TO220 (RoHS) 1 Q10
Miscellaneous
122-14350j4180-e choke coil 35uH Ferrite Core 25 Milliohm (RoHS) 1 L2
128-e106ma01k-e
non polarized ELEC LYTIC CAP. 10UF 100V 20% 105 ℃
(RoHS)
2 C16,C17
175-9f40hr2-e
WIRE CONNECTOR & BASE 40PIN PITCH=2.54mm HR2*40
(RoHS)
122-14121m4191-e Ferrite core 日word type LS-A6206-ST EFD-30 (RoHS) 1 L1
MISCELLANEOUS/MECHANICAL
150-r4055903-e Power transformer TT0900304490 (RoHS) 1 T501
152-u602015-e power cord joint heteropolarity SVT FT-26FT bi-insul (RoHS) 1
154-k31505t0-e fuse 3.15A 250V 30mm UL/CSA/PSE (RoHS) 1
155-63032i-e fuse holder HTB-32I 30mm UL/CSA (RoHS) 1 F501
162-10152001-e WIRE UL1617 AWG22 150mm RED 6:6 (RoHS) 1
162-5020d006-e WIRE UL2468 200mm 2.5mmpitch RED/WHT (RoHS) 1
162-50552003-e WIRE UL1007 #16 550mm (RoHS) #110/#205 0.5T 1
176-wjce1-e dead end CE-1 (RoHS) 1
180-prf1003s-e power switch ROCK RF-1003-BB2-OHA(RoHS) 1 SW501
193-201815t2-e ceramic insulator (RoHS) 2 for Q10,Q11
302-AL-00373-1BGE aluminium rear board 270*215*2.5T anode black (RoHS) 1
306-ABS-00714-0BAE
plastic rear housing 268*213*102 spout conductive paint
(RoHS)
1
311-ABS-00028-0BAE plastic KNOB 46077-W soft material P.V.C.(RoHS) LEVEL 1
317-000-00037-0LAE earth terminal M3 lug plate t=0.3 (RoHS) 1
323-AL-00056-0LAE heat sink 83.5*50.5*27.5H defat 1
333-EVA-00096-0BAE Gasket pad wide sides 213*15*2.0mm (RoHS) 2
333-EVA-00097-0BAE Gasket pad wide sides 213*15*1.0t (RoHS) 2
333-EVA-00121-0BAE 8PIN BB Gasket (RoHS) 1
333-EVA-00132-0BAE Gasket pad long sides 238*15*2.0mm (RoHS) 2
333-EVA-00133-0BAE Gasket pad long sides 238*15*1.0t (RoHS) 2
333-EVA-00188-0BAE Gasket pad 170x5x1t glue on back (RoHS) 1
333-EVA-00219-0BAE Gasket pad wide sides 150*15*1t UL (RoHS) 2
333-EVA-00220-0BAE Gasket pad long sides 225*15*1t UL (RoHS) 1
333-EVA-00866-0BAE Gasket 48*18*1.5T (RoHS) 1
335-NYL-00002-0BAE WIRE CLIP 4K-4 NO-BB(RoHS) 1
335-NYL-05015-0BAE power cord fixed button SB4F-2 黑色(RoHS) 1
350-EM04012D024-E 4*12 wood screw electrical back (RoHS) 4
351-AM03008A078-E M3*8 machine screw nickel plating (RoHS) 4
351-AM03008A079-E M3*8 machine screw electrical back (RoHS) 4
352-AM03008D040-E 3*8 type ping screw electrical back (RoHS) 2
352-AM03008D041-E 3*8 type ping screw nickel plating (RoHS) 2
352-AM03010D065-E 3*10 P type ping electrical back (RoHS) 3
352-HM03012D086-E 3*12 type ping screw electrical back (RoHS) 1
353-0870122-E machine screw M8*70 round head electrical back (RoHS) 1
362-FE-00013-0LAE PCB support L TYPE t=1.6mm S.P.C.C 89*9*1.6T (RoHS) 2
SUB-TS18 harman/kardon
