Harman JBL BAR 9.1 - Page 15

General specication:
• Model: BAR 9.1 CNTR (soundbar unit)
BAR 9 .1 SURROUND (detachable speaker)
BAR 9.1 SUB (subwoofer unit)
• Power supply:
100 - 240 V AC, ~ 50/60 Hz
• Lithium battery: 3.7 V, 6000 mA, 22.2 Wh
• Total speaker power output
(Max. @THD 1%): 820 W
• Soundbar output power
(Max. @THD 1%): 400 W
• Surround speaker output power
(Max. @THD 1%): 2 x 60 W
• Subwoofer output power
(Max. @THD 1%): 300 W
• Soundbar transducer: 4 x racetrack drivers + 4
x up-firing full-range drivers+ 5 x 0.8” tweeters
• Subwoofer transducer: 10”
• HiNA device: < 6 W
• Operating temperature: 0°C - 45°C
HDMI specication:
• HDMI Video input: 1
• HDMI Video output (with enhanced
Audio Return Channel, eARC): 1
• HDMI HDCP version: 2.3
Audio specication:
• Frequency response: 34Hz - 20KHz
• Audio inputs: 1 Optical, Bluetooth, USB
(USB playback is available in US version.
For other versions, USB is for service only.)
USB specication:
• USB port: Type A
• USB rating: 5 V 500 mA
• Supported file format: MP3
• MP3 codec: MPEG 1 Layer 2/3, MPEG 2
Layer 3, MPEG 2.5 Layer 3
• MP3 sampling rate: 16 KHz - 48 KHz
• MP3 bitrate: 80 kbps - 320 kbps
Wireless specication:
• Bluetooth version: 4.2
• Bluetooth prof i le: A2DP V1.2 , AVRCP V1.5
• Bluetooth frequency range:
2402 MHz - 2480 MHz
• Bluetooth Max. transmitting power:
<11dBm (EIRP)
• Modulation Type: GFSK, π/4 DQPSK, 8DPSK
• Wi-Fi network : IEEE 802.11 a/b/g/n/ac
(2.4GHz/5GHz)
• 2.4G Wi-Fi frequency range:
2412 – 2472 MHz (2.4GHz ISM Band,
USA 11 Channels, Europe and others
13 Channels)
• 2.4G Wi-Fi Max. transmitting power:
< 20 dBm (EIRP)
• Modulation Type: DBPSK, DQPSK, CCK,
QPSK, BPSK, 16QAM, 64QAM
• 5G Wi-Fi frequency range:
5.15 - 5.35 GHz, 5.470-5.725 GHz,
5.725 - 5.825 GHz
• 5G Wi-Fi Max. transmitting power:
< 22 dBm (EIRP)
• Modulation Type: QPSK, BPSK, 16QAM,
64QAM, 256QAM
• 5G wireless frequency range:
5725 ~ 5850 MHz
•
•
5G Max. transmitting power: < 13 dBm
(EIRP)
Modulation Type: QPSK
Dimensions:
• Dimensions (W x H x D):
884 x 59 x 120mm / 34.8 x 2.3 x 4.7 inches
(soundbar );
160 x 59 x 120 mm / 6.3 x 2.3 x 4.7 inches
(detachable surround speaker, per piece);
305 x 440 x 305mm / 12.0 x 17.3 x 12.0 inches
(subwoofer)
• Weight:
3.64 kg (soundbar);
0.72 kg x 2 (detachable surround speaker);
11.10 kg (subwoofer)
Generelle specikationer:
• Model: Bar 5.1 CNTR (soundbar), BAR 5.1
SUB (subwoofer)
• Strømforsyning: 100 - 240V AC, ~ 50/60Hz
• Samlet højttalerudgang (max. @THD
1 %): 550W
• Soundbars udgangseffekt (max. @THD
1 %): 5 x 50W
• Subwoofers udgangseffekt (Maks. @THD
1%): 300W
• Soundbar-enheder: 5 x racetrack-enheder
+ 2 x 1,25” diskanter på siden
• Subwoofer-enhed: 10”
• standby-strøm i netværk: <2,0W
• Driftstemperatur: 0 °C - 45 °C
HDMI specikation:
• HDMI-videoindgange: 1
• HDMI-videoudgang med ARC (Audio
Return Channel): 1
• HDMI HDCP-version: 2.3
Lydspecikation:
• Frekvensområde: 34 Hz – 20 KHz
• Lydindgange: 1 optisk, Bluetooth, USB
(USB-afspilning understøttes i den
amerikanske version. For andre versioner
er USB kun til service.)
USB-specikationer:
• USB-port: Type A
• USB-rating: 5V DC, 0,5A
• Understøttede filformater: mp3
• MP3 Codec: MPEG 1 lag 2/3, MPEG 2 lag
3, MPEG 2,5 lag 3
• MP3 samplingrate: 16KHz – 48 KHz
• MP3 bitrate: 80 kbps – 320 kbps
Trådløs specikation:
• Bluetooth-version: 4.2
• Bluetooth- profil : A2DP V1.2 , AVRCP V1.5
• Bluetooth-frekvensområde:
2.402MHz – 2.480MHz
• Bluetooth maks. sendekapacitet:
<11dBm (EIRP)
• Modulationstype: GFSK, π/4 DQPSK,
8DPSK
• Wi-fi-netværk: IEEE 802.11 a/b/g/n/ac
(2,4GHz/5GHz)
• 2,4G wi-fi-frekvensområde:
2.412-2.472MHz (2,4 GHz ISM-bånd,
USA 11 kanaler, Europa og andre steder
13 kanaler)
• 2,4G maks. Wi-fi sendekapacitet: <20dBm
• Modulationstype: DBPSK, DQPSK, CCK,
QPSK, BPSK, 16QAM, 64QAM
• 5G wi-fi-frekvensområde:
5,15 - 5,35GHz, 5,725 - 5,825GHz
• 5G maks. wi-fi-sendekapacitet: <22dBm
• Modulationstype: QPSK, BPSK, 16QAM,
64QAM, 256QAM
• 5 G trådløs frekvensområde:
5.736,35 - 5.820,35MHz
• 5G maks. sendekapacitet: <9dBm (EIRP)
• Modulationstype: π/4 DQPSK
Mål:
• Mål (B x H x D): 1.018 x 58 x 100mm /
40,1”x 2,3” x 3,9” (Soundbar); 305 x 440 x
305mm / 12,0”x 17,3”x 12,0” (Subwoofer)
• Vægt: 2,85KG (Soundbar);
10,62Kg (Subwoofer)
