19: Unscrew below 2 screws and take out Key PCBA
b
4
2
18: Unscrew below 2 screws and take out LED PCBA
c
6
3
a
17: a. Take out Type-C socket
b. Teal off volume silicone button
c. Teal off power silicone button
5
1
16: Unscrew below 6 screws
