- 4 -
07 3.5mm audio jack
08 USB-C port
09 Voice focus boom microphone
• Flip up to mute, or flip down to unmute the microphone.
10 Flat-fold ear cup
11 button
• Press to mute or unmute the microphone.
• Hold for more than 5 seconds to turn the RGB light on or off.
12 Status LED (Power / 2.4G)
13 slider
• Slide upwards / downwards to power on / off the headset.
• Slide upwards and hold for more than 5 seconds to enter 2.4G pairing mode.
Controls on 2.4G USB wireless dongle
01
02
01 CONNECT button
• Hold for more than 5 seconds to enter 2.4G wireless pairing mode.
02 LED
• Indicates the status of 2.4G wireless connection.
