25
Save These Instructions 3-90-775R36_09/15
Feed Limit Adjustment
The Circuit board runs on a one minute timer cycle. Each
minute,theboardisthinkingaheadtowhatitneedstodo
for the next minuteto maintain orachieve the demanded
temperature.WhatyouaresettingontheFeedLimitdialis
themaximumamount of feedtime,perminute, thatyou'll
allow.
The circuit board will make its own determination of how
long to run the feeder, UP TOthemaximum,assetonthe
dial. For instance, a number 4 setting on the Feed Limit
will allow a maximum of 40 seconds per minute of feed.
If the room temperature is satised, with only feeding 20
seconds, then that is all the circuit board will run the feeder.
Whenheatingalargearea,thenumber4settingisusually
adequate, however, fuel quality may dictate a higher or
lower setting. If you see unburned or burning fuel being
pushed off of the grate during a high demand period, the
feed rate is set too high. Ideally, you'll want to see about
aninchofashesinfrontoftheburningfuelduringapeak
demandperiod.Whentheapplianceislocatedinasmaller
roomorarea,theFeedLimitmayneedtobekeptatalower
settingof#2or#3,tomaintainarewithlessfrequentshut-
downandignitioncycles.Alwaysallowaminimumoffteen
minutesbetweenmakinganyadjustmentstothefeedrate.
Note: Since the circuit board is feeding as needed,
only adjust the feed rate while maximum demand is
occurring. (Constant Burn Mode, with a temp dial
settingof#7willcreatemaximumdemand.)
Mode Selection
Room-Tempmodeistheidealmodeofoperationifyouwish
to maintain a comfortable temperature in the room. As the
outdoor temperature uctuates, the control will adjust the
feed rate to maintain the desired temperature setting in the
room. For best results, be sure the room sensor is located
awayfromdraftyareas and not positionedontheooror
nearanexteriorwall.
Constant Burn mode is more of a manual method of
operation. The stove will run at a constant heat output,
regardless of surrounding air temperature. Note that on the
coldest days, your indoor heated space will be cooler than
onthewarmerdays.Theonlyrealbenettothismodeof
operation is that you'll be able to know exactly how long
a hopper full of fuel will last, because the consumption is
going to stay relatively the same.
Temperature Dial
Thetemperaturedialisadualpurposedial.InRoom-Temp
mode, you select the room temperature you want the stove
to maintain at the room sensor probe. This is marked in
Fahrenheit scale from 50 to 90 degrees. In Constant Burn
mode,youselectatemperaturesettingbasedonthe#1-7
with1beingaminimumburnand7beingamaximumburn
rate.
Blower Speed Adjustment
ThemodeselectorisalsomarkedwithaLtoHscaleineach
mode. This is a variable speed control for the distribution
blower. L is the low setting, and H is the high setting. It
is important to note that the blower will not come on until
theESPreachesaspecictemperature,toensurethatcold
air is not being blown out into the room. Also, the speed
of the blower, when set on lower speeds, will automatically
increase as the temperature of the stove increases.
Igniter Auto Mode Switch
The toggle switch for the igniter is a two position switch.
Select from either Igniter Auto or Disabled.
Igniter Auto - Will automatically start the re in either
Constant Burn or Room Temp mode.
Constant Burn: The ignition mode will start the re one
time only. Since Constant Burn maintains a constant output,
therewillnevergoouttoneedre-ignited.
Room Temp:Theignitionmodewillstarttherstre.Then,
iftheroomtemperatureissatised,therewillgoout.Once
theroomcools,theignitionmodewillstartanotherre,and
so on. This mode provides fully automatic temperature
control.
Disabled-Theremustbestartedmanuallyusingstarting
gelorothermanufacturedrestarter.
Disabled-WiththeigniterswitchintheMANUAL position,
the igniter is disabled.
Constant Burn:Therewouldneedtobestartedmanually,
and will maintain a constant output based on the temperature
setting.
Room Temp:Therewouldneedtobestartedmanually.
The control will adjust output to maintain a constant room
temperature,howeveritwillnotallowtheretogoout.If
the room temperature is satised, the control will adjust
to the minimum burn rate and hold there until the room
temperature decreases.
