Harman P35I - E. Custom Size Surround

45
Save These Instructions3-90-775R36_09/15
Minimum Width - 40"
1016mm
P35i Custom Surround
Part #: 1-00-774221-SPL
The top of the mounting frame
must be covered at this point.
Arched - Minimum
Side Height
24-7/8”
632 mm
Arched - Minimum
Center Height
31-3/8”
797 mm
Rectangular
Minimum Height
28-7/8”
733 mm
E. Custom Size Surround
Thisdiagramshowstheminimumdimensionsofacustomtsurroundpanel,partnumber1-00-774221-SPL.Note that
archedsurroundscanonlybemadeat.Therefore,theintakeairslots,normallyinthesidesofthesurround,aremovedto
theface.Rectangularsurroundscanbemadeatifdesired,andtheywillalsohavetheintakeslotsintheface.
