4.4: AUX MASTER
CONSOLE ROUTING > AUX MASTER CHANNEL
4.4: AUX MASTER ROUTING
The Aux Bus sum is sent to the Aux Master output level control. This sum is made up of the aux send
SUHIDGHFRQWULEXWLRQVIURPHDFKFKDQQHO7KDWLVWKHVHQGVDUHWDNHQEHIRUHWKHLQSXWFKDQQHOIDGHU
and are not affected by the input channel fader levels.
The Aux Master Channel can also be used to feed monitors, such as headphones or a stage monitor.
Notepad-8FX
The Aux bus is additionally sent to the built-in Lexicon effects processing after the bus master control.
Notepad 12FX
The Aux bus is additionally sent to the built-in Lexicon effects processing before the bus master control.
See section 6 for more details.
NOTEPAD 5, 8FX, 12FX 8VHU0DQXDO
