Harman Soundcraft Notepad 5 User Manual

7.1: NOTEPAD USB
7.1:NOTEPAD USB
NOTEPAD 5, 8FX, 12FX 8VHU0DQXDO
1RWHSDG
Using the Soundcraft USB Audio Control Panel for PC on the Soundcraft.com website, users can se-
lect the “Audio Routing” tab, to select the point in the console feeding the USB bus to computer.
For Inputs 1+2, users can select from:
Mic Input 1 + Mono line input 2
Stereo Input 2+3
Stereo Input 4+5
Mix L+R
USB return will come into the input channel 4+5, which is the channel where the USB-B connector is
DWWDFKHG7KLVVLJQDOLVVXPPHGZLWKVLJQDOFRPLQJLQWKH5&$MDFNVEHIRUHSURFHHGLQJGRZQWKH
input channel strip.
1RWHSDG);
Using the Soundcraft USB Audio Control Panel for PC on the Soundcraft.com website, users can se-
lect the “Audio Routing” tab, to select the point in the console feeding the USB bus to computer.
For Inputs 1+2, users can select from:
Mic Inputs 1+2
Stereo Input 3+4
Stereo Input 5+6
Mix L+R
USB return will come into the input channel 7+8, which is the channel where the USB-B connector is
DWWDFKHG7KLVVLJQDOLVVXPPHGZLWKVLJQDOFRPLQJLQWKH5&$MDFNVEHIRUHSURFHHGLQJGRZQWKH
input channel strip.
1RWHSDG);
Using the Soundcraft USB Audio Control Panel for PC on the Soundcraft.com website, users can se-
lect the “Audio Routing” tab, to select the point in the console feeding the USB bus to computer.
)RU,QSXWVWKHURXWLQJLV¿[HGIURP
Mic Inputs 1+2
For Inputs 3+4 the routing can be selected from:
Mic Input 3+4
Stereo Input 5+6
Stereo Input 7+8
Mix L+R
USB return will come into the input channel 9+10, which is the channel where the USB-B connector is
DWWDFKHG7KLVVLJQDOLVVXPPHGZLWKVLJQDOFRPLQJLQWKH5&$MDFNVEHIRUHSURFHHGLQJGRZQ
the input channel strip.
