The TL300 offers a unique
stainless steel cooking grill
that can easily be taken in
and out of the stove for easy
cleaning.
The TL300 is designed to accommodate the use
of outside air introduced directly to the stove. The
opening is located at the back of the stove pedestal
base. You'll notice there is a rounded hole with the
etching of a larger hole. The size needed depends
on the length of pipe being used.(see below)
Check with your local building inspector to nd out
requirements determining if outside air is needed
when installing the TL300 in your area. Some
signs to watch for that indicate a possible need for
outside air: Poor performance of other heaters or
of the TL300, including smoke roll-out and odor;
the disappearance of the same symptoms when a
window is opened near the stove; and condensation
on windows in the winter. Modern homes with tight
windows and doors, vapor barriers, and particularly
with exhaust systems are the most likely to require
outside air.
An outside air duct less than 5' (1525 mm) long
may be 3" [80mm] in diameter, and be made of
masonry tile, 26 gauge (0.019) galvanized steel, or
other approved noncombustible material; it should
have a 1" (25 mm) clearance to combustibles.
Systems longer than 5' (1525 mm), or containing
more than two elbows, should have a 4" (100
mm) diameter duct to provide an adequate ow of
combustion air. The air duct must terminate outside
the dwelling and be screened to keep out debris,
birds or animals.
The optional 105 cfm blower helps
circulate heated air throughout
the home. It installs easily onto
the back of the stove, using the
included mounting plate.
The brushed stainless steel
trim kit adds elegance to the
TL300. The kit includes the
door frame, ash lip trim, and
tile frame.
Your Harman TL300 can be burned like a replace
with the optional Cozy Screen. The Cozy Screen can
be used with either the door in place or with the door
removed from the stove. When using the Cozy Screen,
the damper bypass must stay in the open position or
smoke spillage will occur.
The Cozy Screen can be used from the start of a re
or can be used with an existing one. When starting a
re with the Cozy Screen, smoke spillage may occur
until it develops a draft strong enough to pull all smoke
back into the ue.
