4
ASSEMBLY INSTRUCTIONS FOR BKP PORTABLE MODELS
Assembly is the same as for BKM Models
except for the following:
Proceed exactly as with BKM before Step 5.
1. Slip bolts through holes in accessory
bracket before proceeding to tighten nuts, etc.
2. Slide axle into holes on axle bracket.
3. Slip one (1) washer on each side of axle
before putting on wheels.
4. Slip on wheels with grease fittings to the
outside.
5. Add one washer to axle on each side and
then slip cotter pins in place on each side
of axle.
**WARNING** Electrical wiring must be done by a qualified electrician to federal,
state, and local codes. A ground fault circuit interrupter must be installed at receptacle to protect
all electrical components.
All electrical components specified and supplied by others.
HOW TO REMOVE AND REPLACE
CARTRIDGE CLUSTER FOR CLEANING
on residential Betterfilter
®
Models BF42, BF84, BF96,
BF126, BF144 and Models BF42 BKM, BF84 BKM, BK96 BKM, BF126 BKM,
BF144 BKM and the Model BKP Portable Filter
1. Turn off pump.
2. Unscrew wing nuts, lift lid from
filter.
3. Remove cartridge cluster from
housing
4. Clean cartridge cluster as
described on cover.
5. Return cluster to housing. Replace
gaskets properly.
6. Grease studs; replace wing nuts,
hand tighten securely.
1. Follow above steps to remove
cartridge cluster from filter
housing.
2. Unscrew special straight threaded
pipe cap from bottom of cartridge
holding rod.
3. Slip spent cartridges from car-
tridge holding rod.
4. Slip new Harmsco cartridges on
cartridge holding rod.
5. Replace special straight threaded
pipe caps and tighten by hand
so that cartridges are properly
sealed.
6. Follow above steps for replacing
cartridge cluster in filter housing.
How To Install New Cartridges
DO NOT STORE CHEMICALS NEAR FILTER HOUSING
