DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual 3
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
• Re-lockable for DVB-ASI signal
• Reclock status and rate report by LEDs
• Reclocking Bypass mode is selectable as automatic or enforced
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
DA-DH6802+
• Configurable as a single channel of one input and eight outputs
(1×8), or two independent channels of one input and 4 outputs
• Enable automatic switching input between input 1 and input 2 in the
l×8 configuration when a loss of the input signal is detected
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (for 270 Mb/s and
remotely only)
• Direct fanout the input signal (5 Mb/s to 3 Gb/s) without reclocking
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
DA-DSR6802+
• Configurable as a single channel of one input, eight outputs or two
independent channels of one input and 4 outputs
• Enable automatic switching input between input 1 and input 2 in the
l×8 configuration when a loss of the input signal is detected
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (remotely only)
• Reclocking Mode selectable as automatic or manual
• Re-lockable for 270 Mb/s SMPTE signal
• Re-lockable for DVB-ASI signal
• Reclock status and rate report by LEDs
• Reclocking Bypass mode is selectable as automatic or enforced
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
DA-DS6802+
• Configurable as a single channel of one input and eight outputs
(1×8), or two independent channels of one input and 4 outputs.
