Harris DA-H6802+ - Maximum Frame Power Ratings

10 DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 2: Installation
Maximum 6800+ Frame Power Ratings
Power consumption information is listed in Chapter 4: “Specifications”
on page 34.
Table 2-1 describes the maximum allowable power ratings for 6800+
frames. Note the given maximums before installing any 6800+ modules
in your frame.
DA-DHR/DH/DSR/DS/HR/H6802+ modules can be installed in
FR6802+ frames. They cannot be installed in 6800 / 7000 series frames.
Table 2-1. Maximum Power Ratings for 6800+ Frames
6800+ Frame Type
Max. Frame
Power
Dissipation
Number of
Usable Slots
Max. Power
Dissipation Per
Slot
FR6802+XF
(frame with AC power
supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power
supply)
105 W 20 5.25 W
