Chapter 2: ADC-5100 Series Analog Digital Clocks
Specifications
Specifications and designs are subject to change without notice.
Electrical
Inputs and Outputs
Time Base
Table 2-14. Electrical
Item Specification
Electrical voltage 115/230 VAC ±20%, selectable
Frequency 50 or 60 Hz, automatic selection
Table 2-15. Inputs
Item Specification
Serial timecode SMPTE/EBU
Impedance Hi-Z, balanced
Level 4 Vp-p ±8 dB
Table 2-16. Outputs
Item Specification
Serial timecode SMPTE/EBU non-drop frame
Impedance Lo-Z, balanced
Level +10 dB nominal unloaded -3dB
into 180 Ohms
Table 2-17. Time Base
Item Specification
Timecode SMPTE/EBU, automatic selection
Internal Crystal, ± 4 sec/month, 0°—50°C
Power line 50 or 60 Hz, automatic selection
Battery backup Crystal, ± 10 sec/month, 0°—50°C
