RF Communications Division |
1
680 University A
venue | Rochester
, NY USA
1
4610
www
.harris.com
1-585-244-5830
© Copyright 2005 Harris Corporation 08/05 DS-211J
Specifications for the RF-5800H-MP
General
Frequency Range 1.6 to 59.999 MHz
Net Presets 75, fully programmable
Frequency Stability ±0.5 x 10
–6
Emission Modes J3E (single sideband, upper or lower, suppressed carrier telephony)
H3E (compatible AM single sideband plus full carrier)
A1A, J2A (compatible CW), selectable; F3E (FM telephone)
RF Input/Output Impedance 50 ohm nominal, unbalanced
Power Input 26 VDC (20.5 to 32 VDC)
Data Interface Synchronous or asynchronous (RS-232C; MIL-STD-188-114A)
Dimensions (with battery case) 10.5W x 3.5H x 13.2D inches (26.7W x 8.1H x 34.3D cm)
Radio Weight 10 lb (4.7 kg) without batteries
Receiver
Sensitivity SSB: –113 dBm (0.5 µV) for 10 dB SINAD
Audio Output 15 mW at 1000 ohm to external handset
Squelch Front panel adjustable, active squelch selectable
IF Rejection Greater than 80 dB
Image Rejection Greater than 80 dB (1st IF image)
AGC Mode dependent, automatically selected
Intermodulation Distortion –80 dB or better for two –30 dBm signals separated 30 kHz or more
Overload Protection Receiver protected to 32 VRMS
Transmitter
Power Output 1, 5, 20 watts PEP/Average -1/+2 dB (1, 5, 10 watts FM)
Audio Input 1.5 mV at 150 ohm or 0 dBm at 600 ohm for full rated output
Carrier Suppression Greater than 60 dB below PEP output (J3E mode)
Undesired Sideband Suppression Greater than 60 dB below PEP output
Spurious Outputs –50 dB relative to rated output, except harmonics which are –40 dB
(Greater than 20 kHz from Fc) minimum for f
o
= 1.6-30 MHz
Antenna Tuning Capability OE-505 10-foot (3 m) whip (1.6 to 60 MHz)
RF-1936P (AS-2259) NVIS (3.5 to 10 MHZ)
RF-1940-AT001/RF-1941 dipole
Environmental
Test Method Per MIL-STD-810F
Vibration Ground Tactical
Immersion 3 ft. (.9m) of water
Operating Temperature –40˚C to +70˚C
Features
Encrypted Data HF: MIL-STD-188-110B App. C (9600 bps and 12,800 bps uncoded),
App. B 39-tone (2400 bps), (maximum data rate)
Serial T
one (2400 bps),
STANAG 4285 (2400 bps), STANAG 4415 (75 bps),
STANAG 4539 (9600bps), FSK (600 bps)
VHF: FSK (16 Kbps)
Automatic Link Establishment (ALE) STANAG 4538 FLSU, MIL-STD-188-141B Appendix A
Frequency Hopping Serial Tone ECCM
V
ocoder
HF: LPC-10-52E (600/2400), MELP (600/2400), VHF: CVSD
Data Link Layer Protocol (ARQ) STANAG 4538 (3G), pFED-STD-1052
System Configuration
Digital Encryption GPS
RF-5800H-MP025
Citadel
—
RF-5800H-MP026 Citadel Internal
RF-5800H-MP035 Datotek/Citadel —
RF-5800H-MP036 Datotek/Citadel Internal
Major System Components
RF-5800H-V006 20 W
att V
ehicular Adapter
RF-5832H 125 Watt Power Amplifier
RF-5833H 150 Watt Vehicular Adapter Unit
RF-5834H 400 Watt Power Amplifier
RF-5382H 150 Watt Antenna Coupler
RF-382A 400 W
att Antenna Coupler
RF-5845H Pre/Post Selector
FALCON and Citadel are registered trademarks of Harris Corporation.
Specifications are subject to change without notice.
