HART HGHBL02 User Manual

5 – English
ELECTRICAL (AC)
Aproperextensioncordisavailableatanauthorizedservice
center.
Make sure the cord and extension cord are securely attached
as shown in Figure 5, then connect the plug end of the power
cord into the receptacle end of the extension cord. Check
that connection is secure.
**Ampere rating (on product data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25´ 16 16 16 16 14 14
50´ 16 16 16 14 14 12
100´ 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit
NOTE: AWG = American Wire Gauge
WARNING:
Keep the extension cord clear of the working area.
Position the cord so that it will not get caught on
lumber, tools, or other obstructions while you are
working with a power tool. Failure to do so can result
inseriouspersonalinjury.
WARNING:
Check extension cords before each use. If damaged
replaceimmediately.Neveruseproductwithadam-
aged cord since touching the damaged area could
causeelectricalshockresultinginseriousinjury.
To reduce the risk of electric shock, this appliance has a
polarizedplug(onebladeiswiderthantheother)andwill
requiretheuseofapolarizedextensioncord.Theappliance
plugwillfitintoapolarizedextensioncordonlyoneway.If
theplugdoesnotfitfullyintotheextensioncord,reverse
the plug. If the plug still does not fit, obtain a correct polar-
izedextensioncord.Apolarizedextensioncordwillrequire
theuseofapolarizedwalloutlet.Thisplugwillfitintothe
polarizedwalloutletonlyoneway.Iftheplugdoesnotfit
fullyintothewalloutlet,reversetheplug.Iftheplugstilldoes
not fit, contact a qualified electrician to install the proper wall
outlet.Donotchangetheequipmentplug,extensioncord
receptacle, or extension cord plug in any way.
WARNING:
To reduce the risk of electric shock, use only with an
extension cord intended for outdoor use, such as an
extension cord of cord type SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A. or SJTOW-A.
DOUBLE INSULATION
Doubleinsulationis aconcept insafetyin electricpower
tools, which eliminates the need for the usual three-wire
grounded power cord. All exposed metal parts are isolated
from the internal metal motor components with protect-
ing insulation. Double insulated tools do not need to be
grounded.
WARNING:
The double insulated system is intended to protect the
user from shock resulting from a break in the tool’s in-
ternalinsulation.Observeallnormalsafetyprecautions
toavoidelectricalshock.
NOTE:Servicingofaproductwithdoubleinsulationrequires
extreme care and knowledge of the system and should be
performedonlybyaqualifiedservicetechnician.Forservice,
wesuggestyoureturnthetooltoyournearestauthorized
servicecenterforrepair.Alwaysuseoriginalfactoryreplace-
mentpartswhenservicing.
ELECTRICAL CONNECTION
This product has a precision-built electric motor. It should
be connected to a nominal 120V/60Hz AC (typical U.S.
household circuit). Except with battery pack installed, a
substantialvoltagedropwillcausealossofpowerandthe
motorwilloverheat.Ifyourproductdoesnotoperatewhen
plugged into an outlet, double-check the power supply.
GFCI
Ground Fault Circuit Interrupter (GFCI) protection should
beprovidedonthecircuit(s)oroutlet(s)tobeusedforthe
product. Receptacles are available having built-in GFCI
protection and may be used for this measure of safety.
EXTENSION CORDS
When using a power product at a considerable distance from
a power source, be sure to use an extension cord that has
the capacity to handle the current the product will draw. An
undersizedcordwillcauseadropinlinevoltage,resultingin
overheatingandlossofpower.Usethecharttodetermine
theminimumwiresizerequiredinanextensioncord.Only
roundjacketedcordslistedbyUnderwriter’sLaboratories
(UL) should be used.
When working outdoors with a product, use an extension
cord that is designed for outside use. This type of cord is
designated with “W-A” or “W” on the cord’s jacket such
as an extension cord of cord type SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A or SJTOW-A.
Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
