HART HPDD50 - Assembly Instructions; Tool Operation

5 – English
ASSEMBLY
OPERATION
WARNING:
Donotusethisproductifitisnotcompletelyassembled
orifanypartsappeartobemissingordamaged.Useof
aproductthatisnotproperlyandcompletelyassembled
orwithdamagedormissingpartscouldresultinserious
personalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesorattachmentsnotrecommendedforuse
withthisproduct.Anysuchalterationormodificationis
misuseandcouldresultinahazardousconditionleading
topossibleseriouspersonalinjury.
Ifanypartsaredamagedormissing,pleasecall1-800-776-5191forassistance.
WARNING:
Donotallowfamiliaritywiththisproducttomakeyou
careless.Rememberthatacarelessfractionofasecond
issufficienttoinflictseriousinjury.
WARNING:
Always remove battery pack from the tool when you
are assembling parts, making adjustments, cleaning,
orwhennotinuse.Removingbatterypackwillprevent
accidental starting that could cause serious personal
injury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesandotherpossible
seriousinjuries.
WARNING:
Do not use any attachments or accessories not
recommendedbythemanufacturerofthisproduct.The
useof attachments oraccessories not recommended
canresultinseriouspersonalinjury.
APPLICATIONS
Youmayusethisproductforthepurposeslistedbelow:
Drillinginalltypesofwoodproducts(lumber,plywood,
paneling,compositionboard,andhardboard),ceramics,
plastics,fiberglass,laminates,andmetals;drivingscrews
intowoodanddrywallwithscrewdriverbits
CAUTION:
Thisdrillisnotintendedtobeusedformixingconcrete,
drywall, grout or other similar types of viscous
mixtures.Failuretoobeythiscautioncouldcausepoor
performance,possibleinjury,andwillvoidyourwarranty.
INSTALLING/REMOVING BATTERY PACK
See Figure 1, page 9.
Locktheswitchtriggerbyplacingthedirectionofrotation
selectorinthecenterlockposition.
Insertthebatterypackintotheproductasshown.
Makesurethelatchesoneachsideofthebatterypack
snapintoplaceandthebatterypackissecuredinthe
productbeforebeginningoperation.
Depress the latch and pull to release and remove the
batterypack.
For complete charging instructions, see the operator’s
manualsforyourbatterypackandcharger.
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
V
Volts
Voltage
min
Minutes
Time
Direct Current
Typeoracharacteristicofcurrent
n
o
No Load
Speed
Rotationalspeed,atnoload
.../min
Per Minute
Revolutions,strokes,surfacespeed,orbitsetc.,perminute
