GENERAL MAINTENANCE
Avoidusing solventswhencleaning plastic parts. Most
plasticsaresusceptibletodamagefromvarioustypesof
commercialsolventsandmaybedamagedbytheiruse.Use
cleanclothstoremovedirt,dust,oil,grease,etc.
WARNING:
Donotatanytimeletbrakefluids,gasoline,petroleum-
basedproducts,penetratingoils,etc.,comeincontact
withplasticparts.Chemicalscandamage,weakenor
destroyplastic which could resultin serious personal
injury.
REMOVING THE ROLLER BRUSH FOR
CLEANING
See Figure 12, page 10.
Therollerbrushislocatedinsidetherollerbarassembly.
Therollerbarassemblyhasatool-freeendcap,allowing
therollerbrushtobeeasilyremovedforcleaning.
To remove:
 Insert acoinintothesloton the end of the roller
brushasshownoruseyourhand.Rotatetheendcap
approximately1/4in.counterclockwisetounlocktheroller
brush.
Slidethebrushtoreleasethecapandpullthebrushfrom
therollerbarassembly.
NOTE:Usescissorstoremoveany threadsor hair
wrappedaroundthe rollerbrush using the scissor
grooves.
MAINTENANCE
To reattach:
Inserttherollerbrushintotherollerbarassembly.
Alignthetabsonthecaptothenotchesontherollerbar
assemblyandfirmlypressthecapintoplace.
NOTE:Makesuretheoppositeendoftherollerbrushis
alignedtothedrivespindlewhenpressingthecapinto
theassemblyhousing.
Turntheendcap1/4in.clockwisewithcointolockinto
place.
CLEANING/REPLACING THE FILTER
See Figure 13, page 10.

Removethebatterypackandthedustbowl.
Pushtabtoopenthedooronthetopofthedustbowl.
Removethefilterassemblybypullingitoutofthedust
bowl.
Shakeorlightly brush any dust or dirt offthe filter
assembly.
Removethefilterbyliftingawayfromtheassembly.The
filtermayberinsedifnecessary.
Emptythedustbowl;washifnecessary.Beforereattach-
ingtothestickvac,makesureallpiecesarecompletely
dry.
Reinsertthefilterintothefilterassembly.
Installthefilterassemblyintothedustbowl.Reattach
thedustbowlbyaligningtheslotonthebottomofdust
bowlwiththetabonthebottomofmotorhousing,then
rotateandsnapthetwosectionstogether.
NOTE: Allow24hoursforpartstodrycompletely.
When purchasinga replacementfilter assembly, request
recommendedpartnumber903623004.
NOTE: ILLUSTRATIONS START ON PAGE 8 AFTER
FRENCH AND SPANISH LANGUAGE SECTIONS.
