ASSEMBLY INSTRUCTIONS
XB-P / XB-A 6
PART
NAME
Arc Washer
(M8)
4
4
4
8
13
15
Cap Nut
(M8)
Carriage Bolts
(M8 x 50)
PART
DIAGRAM
NO. QT Y.
17
13
8
14
9
15
To align hole site of Foot tube (14) with Main Frame (17), use Carriage Screw (15), Arc Washer
(8), and Cap Nut (13) then connect and tighten Cap Nut (13).
Step 1
PART
NAME
Flat Washer
(M8)
3
3
8
13
M8 Lock Nut
(M8)
PART
DIAGRAM
NO. QT Y.
To align hole site of Seat (9) & Seat Holder (10), use Ø 8.5 Flat Washer (7), M8 Lock Nut (6) to
connect, then tighten M8 Lock Nut (12).
Step 2
10
6
7
