www.hasselblad.com
95
907X CONTROL GRIP USER GUIDE
ATTACHING THE CONTROL GRIP
Place the camera upside-down with the lens mount facing you.
1 Align the lock pin (
A
) and lock screw (
B
) as shown below.
2 Make sure you insert the lock screw in the correct hole.
3 Tighten the lock screw securely (
C
) by hand.
A B
C
