USE
IMPORTANT: You must RESET the desk prior to use.
CAUTION
Make sure no obstacles are in the desk’s path.
Make sure the desktop is not touching any walls.
Make sure all cords are appropriate length to
accommodate the change in height.
Make sure the control box is properly installed
and not hanging loose.
Reset Procedure:
1. Press and hold the DOWN button on the Handset
(part D) until the desk reaches its lowest height.
Release the DOWN button.
2. Press and hold the DOWN button again until the LED
display reads “RST”. Release the DOWN button.
3. Press and hold the DOWN button again until the
desk lowers a little bit more, slightly rises and stops.
Release the DOWN button.
Your desk is now ready to use.
The desk base can be adjusted by pressing and holding
either the UP or DOWN button until the desired height
is reached.
To program up to four presets: Use the up/down
buttons to find a desired height, then press “M”
followed by a number 1 - 4.
CAUTION
Once a preset button is held, the desk will
move to and auto stop at the programmed
height (see caution box above).
CAUTION
If a dierent control box is placed on a desk
with partially extended legs, you must RESET
prior to moving UP.
PROGRAMMING
Press the DOWN button on the Handset until the base
reaches its lowest position. Press and hold the DOWN
button again until the LED display reads “RST”.
Press and hold the 1 button (about 5 seconds) while the
LED flashes “RST” and then switches to either:
10.1 = One-Touch
10.2 = Constant-Touch
Release the 1 button. Press the 1 button again until the
desired setting is reached. Once the chosen setting
is displayed, release the button and wait about 5
seconds for the display to return to “RST”.
Finish the reset process by pressing and holding the
DOWN button until the desk lowers a little bit more, slightly
rises and stops. Release the button. The new program
setting is saved and your desk is now ready to use.
SETTING THE LED
RETRACTED HEIGHT
Press the DOWN button on the Handset until the base
reaches its lowest position. Measure the distance
from floor to the top surface of the desktop. If the
number on the LED display does NOT match your
measurement, follow these steps:
Press and hoId the DOWN button until the LED display
reads “RST”.
Press and hoId the “M” button (about 5 seconds) until the
LED displays the flashing height. (If the display returns to
“RST” before the next step is taken, repeat this step.) Use
the UP /DOWN buttons to change the value of the starting
height so that it matches your measurement. Wait about 5
seconds and the display will return to “RST.”
Finish the reset process by pressing and holding the
DOWN button again until the desk lowers a little bit
more, slightly rises and stops. Release the button. The
new starting height value is saved and your desk is
now ready to use.
Note: the LED display has a ±0.1 tolerance.
SETTING THE UPPER
& LOWER LIMITS
This base is designed to go to its minimum and
maximum heights, allowing for the widest possible
range. If you prefer to change the settings to a more
narrow range, follow these steps:
Make sure the power is ON and a number reads in the
LED display (if no number appears, please follow the
Reset procedure described in the USE section).
To Set the Upper-Limit Position:
Use the UP /DOWN buttons to move the base to the
desired maximum-height position. Press the “M”
button and release. Press the UP button and release.
The LED display will flash “S -”. Press and hold the “M”
button (about 2 seconds) until the LED display changes
to “999”. The display will automatically return to the
selected height. The new upper limit is now set.
To Set the Lower-Limit Position:
Use the UP /DOWN buttons to move the base to the
desired minimum-height position. Press the “M” button
and release. Press the DOWN button and release.
The LED display will flash “S -”. Press and hold the “M”
button (about 2 seconds) until the LED display changes
to “000”. The display will automatically return to the
selected height. The new lower limit is now set.
To Remove the Upper/Lower Limit Positions:
Press and hold the “M” button until the LED display
flashes “S -” and then release it. Within 5 seconds,
press the “M” button again and hold for 2 seconds. The
LED display will change to “555” and then automatically
return to the height display. The upper and lower limits
are now removed.
CAUTION
A RESET procedure requires the desk base to
full retract (beyond any lower limit set).
Please ensure that you have the proper
clearance below the desk base.
continued on page 18
