HAT MID HAT - Specifications

MODEL BASE WEIGHT HEIGHT RANGE
CLEARANCE
UNDER BASE
WIDTH RANGE
LOAD RATING
W/WORKSURFACE
MAX SPEED
HAT2-HI-S-X X 70 lbs. 23.75"- 49" 20" 24"-41" 250 lbs. 1.5" per second
HAT2-HI-L-XX 74 lbs. 23.75"- 49" 20" 42"-74" 250 lbs. 1.5" per second
HAT2-MID-S-X X 64 lbs. 27.25"- 46.75" 23" 24"-41" 250 lbs. 1.2" per second
HAT2-MID-L-XX 68 lbs. 27.25"- 46.75" 23" 42"-74" 250 lbs. 1.2" per second
Note: The 250 lbs load rating includes the weight of the worksurface itself.
Duty Cycle – 2 Minutes On / 18 Minutes O
Power Rating: 120VAC, 60Hz, 4A
SPECIFICATIONS
PAGE 3 OF 22
