Form No. EBOOSTERM-0406
4
MODEL DESCRIPTIONS
ALL MODELS
Hatco Electric Water Booster Heaters are available
in three models: Imperial, Compact and Mini-
Compact. All standard models include a booster
heater with low-water cut-off system,
temperature/pressure relief valve, pressure
reducing valve with built-in high pressure bypass,
two temperature/pressure gauges and a high
temperature limit safety switch.
IMPERIAL MODELS “S” SERIES
Hatco Imperial models feature a Castone
®
tank with
a 10 year limited warranty, an ON/OFF switch,
an indicator light and 6" (152 mm) legs. Imperial
units have a capacity of 16 gallons (61 liters) and
provide up to 573 gph (2169 lph) of sanitizing rinse
water based on a 40°F (22°C) temperature rise.
COMPACT MODELS “C” SERIES
Hatco Compact models feature a Castone
®
tank with
a 10 year limited warranty, an ON/OFF switch,
an indicator light and either 6" (152 mm) legs or
slide mounting brackets for mounting under a dish
table. Compact units have a capacity of 6 gallons
(23 liters) and provide up to 573 gph (2169 lph) of
sanitizing rinse water based on a 40°F (22°C)
temperature rise.
MINI-COMPACT MODELS “MC” SERIES
Hatco Mini-Compact models feature a stainless
steel tank and 6" (152 mm) legs. Mini-Compact units
have a capacity of 3.2 gallons (12 liters) and provide
up to 114 gph (432 lph) of sanitizing rinse water
based on a 40°F (22°C) temperature rise. Ideal for
either hot water sanitizing or point-of-use hot water
dispensing.
Figure 1. Imperial Model
Figure 2. Compact Model
Figure 3. Mini-Compact Model
