Form No. TQ2CEM-1105
ILLUSTRATIONS
A Top Heat Control A Oberhitze-Wärmeregler
B Color Control B Steuerung Bräunungsgrad
C Bottom Heat Control C Unterhitze-Wärmeregler
D Warning Light D Warnleuchte
E Power Save Mode E Stromsparmodus
F On/Off Switch F Betriebsschalter
A Control de Temperatura A Commande d'élément
Superior Chauffant Supérieur
B Control de Color B Contrôle de Coloration
C Control de Temperatura C Commande d'élément
Inferior Chauffant Inférieur
D Luz de Advertencia D Voyant d'avertissement
E Modo de Ahorro de Energía E Mode Économie d'énergie
F Interruptor de Encendido/ F Interrupteur Marche/Arrêt
Apagado
A Regolatore Temperatura A Warmteregeling Boven
lato Superiore B Kleurregeling
B Regolatore di Doratura C Warmteregeling Onder
C Regolatore Temperatura D Waarschuwingslampje
lato Inferiore E Energiebesparingsmodus
D Spia F Aan/uit-schakelaar
E Modalità riduzione consumo
energetico
F Interruttore On/Off
A Screws A Schrauben
B Security Cover (Flip Down) B Sicherheitsabdeckung (Herunterklappen)
A Tornillos A Vis
B Cubierta de Seguridad (Se Abre Hacia Abajo) B Capot de Sécurité (Rabattable)
A Viti A Schroeven
B Coperchio di Sicurezza (per Aprirlo Girarlo B Veiligheidsdeksel (Neerklappend)
verso il Basso)
A Warning Light A Warnleuchte
B Top Heat Control B Oberhitze-Wärmeregler
C Bottom Heat Control C Unterhitze-Wärmeregler
D Color Control D Steuerung Bräunungsgrad
E Power Save Mode E Stromsparmodus
F On/Off Switch F Betriebsschalter
A Luz de Advertencia A Voyant d'avertissement
B Control de Temperatura B Commande d'élément
Superior Chauffant Supérieur
C Control de Temperatura C Commande d'élément
Inferior Chauffant Inférieur
D Control de Color D Contrôle de Coloration
E Modo de Ahorro de Energía E Mode Économie d'énergie
F Interruptor de Encendido/ F Interrupteur Marche/Arrêt
Apagado
A Spia A Waarschuwingslampje
B Regolatore Temperatura B Warmteregeling Boven
lato Superiore C Warmteregeling Onder
C Regolatore Temperatura D Kleurregeling
lato Inferiore E Energiebesparingsmodus
D Regolatore di Doratura F Aan/uit-schakelaar
E Modalità Riduzione
Consumo Energetico
F Interruttore On/Off
Appliance is malfunctioning
when lit. Turn off power
and allow unit to cool.
See instruction manual
before operating.
Toaster is in Power Save
mode when flashing.
Push button and allow
toaster to heat up
before toasting.
®
®
13
B
A
B
D
E
F
C
C
E
F
A
D
Appliance is malfunctioning
when lit. Turn off power
and allow unit to cool.
See instruction manual
before operating.
Toaster is in Power Save mode
when flashing.
Push button and allow toaster
to heat up before toasting.
14
Control Panel – TQ-400, Bedienfeld – Serie TQ-400,
-800, and -1200 Series -800 und -1200
Panel de Control – Series Panneau de Commande –
TQ-400, -800, y -1200 Séries TQ-400, -800 et -1200
Pannello Comandi – Modelli Regelpaneel – TQ-400,
Serie TQ-400, -800 e -1200 -800 en -1200 Serie
Control Panel – TQ-1800, Bedienfeld – Serie TQ-1800
Models
Panel de Control – Series Panneau de Commande –
TQ-1800 Séries TQ-1800
Pannello Comandi – Modelli Regelpaneel – TQ-1800
Serie TQ-1800
15
A
B
Security Cover Sicherheitsabdeckung
Cubierta de Seguridad Capot de Sécurité
Coperchio di Sicurezza Veiligheidsdeksel
