Hatz 2M41 - Checking that the Air Filter Maintenance Indicator Is Working Properly

2L41C, 2M41, 2M41Z Maintenance
HATZ
81Operator’s Manual
Step Activity
8 Open the fuel feed line.
9 To simplify the starting procedure, it is recommended that you
pre-pump the fuel using the manual lever at the fuel feed pump
until you hear fuel flow back through the return line into the fuel
tank (see the chapter 7.3.1 Pumping fuel with the manual lever,
page 34).
10 Perform a leak tightness test by activating the manual lever.
11 After completion, insert the access cover to the fuel feed pump
back in the side wall.
12 Mount the capsule and air guide parts again.
8.2.16 Checking that the air filter maintenance indicator is working properly
Overview
Electrical
air filter maintenance display
0
I
II
Mechanical
air filter maintenance display
Hose of air intake pipe
