Hatz 4H50TIC - Page 29

Exhaust side
1
2
3
4
5
6
7
8
9
1 Expansion tank for coolant
2 Oil filler plug, top
3 Turbocharger
4 Oxidation catalytic converter
5 Exhaust outlet
6 Starter (high mounting position)
7 Oil drain screw, front
8 Poly v belt
9 Cooler
