Procedure
Step Activity
1 Pull out the dipstick (1) and clean it.
2 Depending on accessibility, unscrew oil filler plug (2) or (4).
3 Fill engine oil. For the specification, viscosity and filling quantity,
see the chapter 4.3 Engine oil, page 22.
4 Reinsert the dipstick.
5 Pull out the dipstick and check the oil level.
6 If required, top up engine oil to the max. mark.
7 Reinsert the dipstick.
8 Screw in the oil filler plug.
Concluding inspection work
Step Activity
1 Check the oil level after a short test run and correct if necessary.
2 Check the oil filter for tightness and retighten by hand if neces-
sary.
8.2.6 Cleaning the radiator fins
Safety notes
DANGER
Danger of explosion from flammable cleaning agents.
Cleaning with benzene is an explosion hazard. It is highly flam-
mable, can become electrostatically charged and can generate
an explosive gas-air mixture.
▪ Use halogen-free, cold cleaners with a high flashpoint for
cleaning.
Maintenance 4H50TIC
64 Operator's Manual
