Pos. Designation
1 Error diagnosis display
2 Service interval indicator
3 Button for error interrogation
4 Protective cap
5 Starting key
6 Pre glow display
7 Air filter service required
8 Engine temperature display
9 Oil pressure display
10 Charge control
11 Operating display
Ignition lock
0 Off
I Operation
II Starting
Procedure
NOTICE
▪ After approx. 20 seconds the start procedure cuts off auto-
matically to protect the starter. If the engine is still not run-
ning after that, turn the starting key back to position "0" and
eliminate the cause (see the chapter 9.1 Fault table,
page 86).
▪ Turn the starting key to position "0" every time you want to
start the engine.
▪ The anti repeat device in the ignition lock makes it impossi-
ble for the starter to engage while the engine is running and
become damaged.
Step Activity
1 Remove the protective cap (4) from the ignition lock.
4H50TIC Operation and use
HATZ
Operator's Manual 43
