8 Parts List
Haug P/N
Title
Detail
Vendor
Vendor P/N
114827
Tank & Lid Assy. 110808
110808
Haug
114826
Tank & Lid Assy. 181210
181210
Haug
114828
Tank & Lid Assy. 201413
201413
Haug
114829
Tank & Lid Assy. 242015
242015
Haug
114710
Tank & Lid Assy. 302015
302015
Haug
116034
Tank & Lid Assy. 322620
322620
Haug
(ALL LID DIMENSIONS ARE FROM THE INSIDE OF THE TANK)
114709
Lid Assy (complete w/ hardware)
Pack Vac, 11x08
Haug
114703
Lid Assy (complete w/ hardware)
Pack Vac, 18x12
Haug
114706
Lid Assy (complete w/ hardware)
Pack Vac, 20x14
Haug
114834
Lid Assy (complete w/ hardware)
Pack Vac, 24x20
Haug
114711
Lid Assy (complete w/ hardware)
Pack Vac, 30x20
Haug
116036
Lid Assy (complete w/ hardware)
Pack Vac, 32x26
Haug
174717C
Lid Plate (with o-ring only)
Pack Vac, 11x08
Haug
174700
Lid Plate (with o-ring only)
Pack Vac, 18x12
Haug
174709
Lid Plate (with o-ring only)
Pack Vac, 20x14
Haug
176225
Lid Plate (with o-ring only)
Pack Vac, 24x20
Haug
174852
Lid Plate (with o-ring only)
Pack Vac, 30x20
Haug
176512C
Lid Plate (with o-ring only)
Pack Vac, 32x26
Haug
194993
Hold Down Assy (bolt on)
Pack Vac, 11x08
Haug
194710
Hold Down Assy (bolt on)
Pack Vac, 18x12
Haug
194855
Hold Down Assy (bolt on)
Pack Vac, 20x14
Haug
194865
Hold Down Assy (bolt on)
Pack Vac, 24x20
Haug
111202
Hold Down Assy (bolt on)
Pack Vac, 30x20
Haug
116037
Hold Down Assy (bolt on)
Pack Vac, 32x26
Haug
910601
Small Annual Preventive Maintenance Kit
201413 Gasket, Vacuum Gauge, 2 hinges, vacuum relief valve
910602
Large Annual Preventive Maintenance Kit
342620 Gasket, Vacuum Gauge, vacuum relief valve, and 4 hinges
General PV Hardware
114996
Vacuum Assy.- side mount
Single venturi (retrofit for Pisco venturi system)
Haug
234362
Knob, tapered
5/16-18 stud
Reid Tool Supply Company
BD-40
234417
Lid Strap
Pack Vac, 1812, 2014,1108
Dakota "AG" Welding, Inc.
851100
Gauge, vacuum
30 IN HG bottom mnt. 3-1/2"- Certified
Any
910033
Hinge, black friction
McMaster-Carr Supply Co.
1791A48
910059
Bumper, rubber (foot)
7/8" Base Dia, 13/32" Proj w/ washer
McMaster-Carr Supply Co.
9540K48
115092
Vac-Pac Attachment
Test attachment for vacuum packed products
Haug
910052
Needle, Dispensing, SS
20 Gauge. 1/2" Long, Yellow, Luer Lock, 50 pcs.
McMaster-Carr Supply Co.
75165A677
910500
24x20 Gas Spring Assembly
(2) Gas Springs, 50 lb (4) Ball Brackets, 10mm Flat Mount
910501
30x20 Gas Spring Assembly
(2) Gas Springs, P3P3F92-100-324/300N (4) Ball Brackets, 13mm Ball
910502
32x26, 34x26 Gas Spring Assembly
(2) Gas Springs, P3P3F92-085-309/670N (4) Ball Brackets, 13mm Ball
Electric PV Parts
801094
Vacuum Pump
1/4HP Gast
Grainger
4F740A
801093
Vacuum Pump
3/4HP Gast
Grainger
4F742A
801097
Light Bulb 110V
Coated, vibration resistant
McMaster-Carr Supply Co.
1532K41
801361
Fuse- Class CC (3/4 HP Pump)
20A time delay
McMaster-Carr Supply Co.
7706K99
801184
Fuse- Class CC (1/4 HP Pump)
12A time delay
McMaster-Carr Supply Co.
7706K31
801111
PVEL Power Cord
14/3 AWG, 10' Length
McMaster-Carr Supply Co.
70355K84
801269
Contact block assy.
Rotary Switch, PVEL
Alameda Electrical Distributors, Inc.
180892
801270
Operator handle
Rotary Switch, PVEL
Alameda Electrical Distributors, Inc.
180906
851008
Mini Filter w/ Twist Drain
1/4" Mini w/ Twist Drain
Motion Industries
F300-02
851039
Valve, slide
Red 1/4" Female NPT
McMaster-Carr Supply Co.
4622K33
851089
Ball, Racquet
Any
851038
T-Strainer
Nylon T-Strainer Clear Bowl, 1" Pipe
McMaster-Carr Supply Co.
9875K56
851441
Check Valve Cartridge Model #150 5/8"
Including 1" NPT Reducer (Press Fit)
Smart Products
150000PB-
0011S000-2064
Parts and suppliers are subject to change without notice. Common parts such as gauges
and regulators are available from numerous sources.
