HAUL MASTER 60708 - Parts List and Diagram; Lower Stem Parts List and Assembly Diagram

Page 10 For technical questions, please call 1-800-444-3353. Item 60708
Parts List and Diagram
Lower Stem Parts List and Assembly Diagram
Part Description Qty
1A Outer Tube 1
2A Inner Tube 1
3A Bronze Nut 1
4A Jack Screw 1
5A Pin 1
Part Description Qty
6A Set Screw 3/8" 1
7A Lock Washer 5/16" 4
8A Cap Screw 5/16" 4
9A Lock Pin 3/8" 1
10A Footpad 1
3A
6A
4A
8A
9A
7A
2A
1A
5A
10A
