- Driving
3.2 - OPERATION FROM GROUND POSITION
3.2.1 - Machine start-up
1. Pull the E-stop button (15).
2. Turn the key of the control box activation selector ( 72 ) to the right to energize the
ground control box. The following indicators light up :
• Electrical pre-heating (1).
• Engine oil pressure (2).
• Engine temperature (3).
• Battery charge (4).
3. For HSX(L) : The clogged air filter indicator ( 5 ) is switched off.
4. For HSX(L) : Press the starter push-button (22). For Compact DX : Push the selector
upwards (123). The engine starts. The indicator goes out.
5. Let the engine heat up.
3.2.2 - Machine shutdown
• Turn the control box activation selector ( 72 ) key to the center.
• The machine is shut down. The power to the machine is switched off, all the indicators on the lower
console are off.
3.2.3 - Movement control
• For Compact 10/12DX (Compact 2668/3368RT) :
N.B.-:-Activate the controls and the 'Enable Switch' system simultaneously to perform the various
movements.
Ground box controls (emergency station)
N.B.-:-Either the selector button or speed selector paddle are released, movement stops.
The ground control box is an auxilary control box to use in emergencies only.
Control Action
Platform raising/
lowering selection
Platform raises :
• Push the console activation selector (72) to the right.
• Push the "Dead man" selector ( 123 ) downwards and the platform raising
and lower selector ( 106 ) upwards simultaneously.
Platform lowers :
• Push the console activation selector (72) to the right.
• Push the "Dead man" selector ( 123 ) and the platform raising and lowering
selector ( 106 ) downwards simultaneously.
