Haulotte HT26RT O User Manual

98 4000611860 E 07.17 USA / EN
HT26RT O - HT28RTJ O - HT28 RTJ PRO - HT80RT O - HT85RTJ O - HT85RTJ PRO
C - Study of the wiring diagram
2.5.5.2 - Actuators
REQUIREMENTS DEFINITION
TRV03
CUT-OFF L R FAILURE CUT-OFF CONDITIONS
6Failure
1 1 1 KMP relay stuck
211
Failure active on turret rotation valve and engine
running
3 1 1 Active failure on LS valve and engine is running
411
Overload failure, machine unfolded and overriding
not active
REQUIREMENTS DEFINITION
TRV03
CUT-OFF L R SPECIFIC CUT-OFF CONDITIONS
7 Specific
11N/A
Activ'Shield Bar active for left turret rotation and
platform control box active
2N/A1
Activ'Shield Bar active for right turret rotation and
platform control box active
REQUIREMENTS DEFINITION
TRV04
Following limitations are applied on the turret rotation left (L) or right (R) set point when engine is running
LIMITATION VALUE (%) LIMITATION CONDITION : AVAILABLE ONLY WHEN ENGINE
IS RUNNING
CTRL[Engine]=RUNNING &
L | R
1 60 Overriding mode is active
2 60 Failure on load management system or on oscillating axle unlocking valve
3 80 Active control box is lower control box
4 60 Tilt is active and machine is unfolded
5 65 Telescope is out
If several limitation conditions are active, lower value is applied ( 100% means full speed)
A limit applied cannot increase during the execution of the movement, even if a condition is no more active
No limitations are applied in case of movement with emergency pump
REQUIREMENTS DEFINITION
TRA01
The following components drive the turret rotation movements :
• YV250: Control movement direction and speed.
• YV250S: Supply of the valve.
• YV805: Orientation safety valve.
• YV805G: Ground of orientation safety valve.
