Haussmann FSN50 - Parts List

12
ENGLISH
N
O.
DESCRIPTION
1 Cylinder Bushing
2 Plunger
3 O-Ring 19.2 x 1.8
4 O-Ring 15.9 x 1.8
5 Poppet
6 O-Ring 42.5 x 5.4
7 O-Ring 17.5 x 2.6
8 O-Ring 57.4 x 3.5
9 Piston Assembly
10 Hammer Face
11 Screw M5 x 20
12 Cylinder Cap
13 Screw M4 x 20
14 Spring Washer 4
15 Poppet Actuator
16 O-Ring 54.2 x 3.5
17 Seal
18 Body
19 Bumper
20 Nose
21 Screw M3 x 20
22 Spring Pin 3 x 14
23 Bafe Plate
24 Screw M5 x 14
25 Spring Washer 5
26 Blade Guide
27 Limited Nail Plate
28 Shoe
29 Joint Guider
30 Bushing
31 Screw M6 x 16
32 25/32” Spacer
32a 1/2” Spacer
33 Screw M6 x 12
N
O.
DESCRIPTION
34 Spring Pin 2 x 14
35 Movable Magazine
36 Spring Washer 6
37 Screw M6 x 35
38 Feeder Shoe
39 Spring
40 Bafe Lock
41 Magazine Plate
42 Screw
43 Spring
44 Screw M4 x 16
45 Limited Plate
46 Lock
47 Nut M4
48 Spring Washer 4
49 Bushing
50 Spring Pin 3 x 12
51 Washer 4
52 Pothook
53 Screw M3 x 5
54 Spring Washer 3
55 Washer 3
56 Leaf Spring
57 Screw M3 x 8
58 Fixed Magazine
59 Spring Pin 2.5 x 10
60 Screw M3 x 6
61 Magnet
62 Rail
63 Nut M4
64 Washer
65 Clamp Screw
66 Air Plug
67 Arm
68 Hammer
PARTS LIST
For parts placement, please refer to the schematic drawing on the preceding pages.
