PACKAGE CONTENTS
In the box check for following items :
Remote Pairing:
NOTE: Remote supplied along with fan is already paired with your fan.
Follow below pairing instructions if your fan remote or PCB is changed.
Following steps have to be executed in correct sequence and all steps should be done within 10 seconds total.
1. Power ON fan, from the main supply.
2. Press the button on the remote once.
3. Press the Fan Speed 1 button on the remote once.
Successful pairing will be conrmed by two beeps from the Fan.
Note: If pairing fails repeat the steps after powering OFF the fan from the mains.
Remote Un-Pairing
To un-pair the unwanted remote, repeat the complete pairing process two times on the remote you want to keep using, with
a minimum 1 minute time between rst and second pairing. The unwanted remote will be automatically unpaired.
Fan Installation:
Blade Installation (Figure 1, 2, & 3)
1. Unfasten blade screw from Motor.
2. Slide blade from top side of motor lugs facing blade sticker upside & align blade hole with motor blade xing boss.
3. Screw blades with Motor and ensure tight t.
4. Ensure all Blades have the same numerical code mentioned on blade sticker, for precise balancing of fan.
IMPORTANT : While tightening the blade screws on motor, ensure that blade prole is not damaged.
Shackle Kit (1 N)
Down-rod (1 N)
Battery (AAA)
(2 N)
Motor with PCB
Controller & Light (1 N)
Canopy Set (1 N) Blade set (1 N)
containing Blades (3 N)
Remote
(1 N)
