Hawk Acoustic Wave Series

Questions and Answers

E
erica00Aug 15, 2025
Why is my Hawk Sonar unit measuring incorrect depth or height?
- L
  Lee RojasAug 15, 2025
  If your Hawk Sonar unit is measuring incorrect depth or height, it could be due to several reasons. First, confirm that the display mode is correct; depth is measured from the sensor face to the target, while height is measured from the low level to the target. Also, confirm that the High Level and Low Level settings match your application requirements. You might also need to adjust the selected 'Density'. A higher density value programs the unit to look for a more dense layer deeper. High volumes of poorly settling or suspended material can cause the unit to read higher by tracking suspended material if process conditions in the tank fail.
T
Thomas JonesAug 20, 2025
How to troubleshoot Hawk Acoustic Wave amplifier when it cannot communicate with the transducer?
- D
  Douglas MarksAug 20, 2025
  If your Hawk Sonar amplifier or transmitter cannot communicate with the transducer, consider the following troubleshooting steps: * Check the terminals for a loose or incorrect wiring connection, including the junction box and cable extensions. * Inspect the cables for any signs of damage. * Ensure that any customer-supplied cable meets Hawk specifications. If you're using a junction box extension, trace the 8-10VDC from the red/black amplifier terminals to the transducer to ensure the wires are correctly connected. Also, if using a junction box, ensure you follow Hawk specifications for extending the cable.
J
John JarvisAug 25, 2025
What to do if Hawk Acoustic Wave Sonar shows voltage error?
- E
  Eric MathewsAug 26, 2025
  If your Hawk Sonar shows a voltage error, and you are using AC power, check the power supply for faults by reading the DC +/- terminals; they should show a stable 16VDC. If the value is lower or inconsistent, there may be a problem with the internal power supply. If the unit detects voltage below 9VDC, performance will be affected. If ‘V in chk’ is on, the unit will trigger its failsafe routine; if ‘V in chk’ is off, the unit will display ‘V fail’ on the LCD. This can be caused by the unit detecting voltage below 9VDC.
B
bonnie23Aug 30, 2025
What causes 'Transducer no. 2 communication error' on Hawk Acoustic Wave?
- E
  Erin HuntAug 30, 2025
  A 'Transducer no. 2 communication error' on your Hawk Sonar can be caused by wiring issues or a problem with the transducer itself. If any circuits are open, check the wiring connections. Transducer problems may cause the amplifier to protect itself against high current draw. Measure the resistance across the transducer: Red and DC:+ terminals on the amplifier while the transducer is disconnected and then connected. If the resistance increases dramatically, there is potentially a wiring or transducer problem.
D
Daniel SwansonSep 3, 2025
What to do if Hawk Measuring Instruments display higher distance than actual level?
- M
  Mark BrownSep 4, 2025
  If your Hawk Measuring Instruments display a distance higher than the actual level, begin by checking the mounting conditions within the vessel and inspecting the distance of any false echoes. Also, consider extending the ‘Blanking’ distance in the TX Setup to eliminate the echo entirely.
J
Joseph CunninghamNov 9, 2025
What to do if PLC indication does not match measurement on Hawk Acoustic Wave Sonar?
- R
  richardhansenNov 9, 2025
  If the PLC indication doesn't match the measurement on your Hawk Sonar, take these steps: * Disconnect the analogue wires from the amplifier and use a multimeter on the 4-20mA terminals labeled IS and + to read the direct mA from the unit. Reconnect the analogue wires and compare this value with the reading from the control system. * Confirm that the High Level and Low Level settings are the same in both the amplifier and the control system. Also, ensure your wiring is correct, paying special attention to the screen (earth). Use a quality shielded instrument cable. If a specific comms mode is selected (e.g., Profibus, FF) but the comms module isn't connected or responding, check your unit's part number to ensure it has the correct comms. If you don't have additional comms (part numbe...
