NO PART QTY
1 Bolt M6×45 8 36 Starting capacitance 1
2 Spring washer 6 8 37 Operation capacitance 1
3 Three angle connecter 1 38 Capacitance cover 1
4 Cylinder head 2 39 Screw ST3.9 x 16 6
5 Cylinder head gasket 2 40 Overload reset 1
6 Valve plate 4 41 Discharge pipe 1
7 Valve slice 4 42 One-way valve 1
8 Aluminium Foil 2 43 Right-angle connecter Rp1/8 1
9 Valve Gasket 2 44 Release pipe 1
10 Cylinder 65 2 45 Tank 1
11 Cylinder gasket 2 46 Wheel 2
12 Piston ring 65 x 2 4 47 Motor belt 1
13 Oil scraper ring 65 x 3 2 48 Axle
14 Piston 65 x 35.5 2 49 Washer 8 4
15 Piston Pin 2 50 Bolt M8 x 30 2
16 Ciclip 14 4 51 Screw M5 x 35 4
17 Connecting rod 2 52 Washer 5 4
18 Breath Pipe 1 53 Plastic mat 8
19 Crankcase 1 54 Net 1
20 Right-angle connecter 1 55 Belt 1
21 Oil leveler G1/2 1 56 Compressor belt wheel 1
22 Oil discharge screw 1 57 Drain cock 1/4″ 1
23 Nut M8 16 58 Washer foot subassembly 2
24 Spring washer 8 21 59 Handle 1
25 Screw M8 x 32 8 60 Screw M8 x 8 4
26 Bearing 6204-2RS 1 61 Power cord 1
27 Crank 1 62 Nut 1/4″ 1
28 Bearing 6205-2RS 1 63 Regulator Valve 1
29 Sealing Ring 1 64 Coupler 2
30 Fasten Plate 1 65 Safety valve 1
31 Bearing Bracket 1 66 Pressure gauge 2
32 Bolt M8 x 25 12 67 Pressure switch 1
33 Washer 10 2 68 Air filter 2
34
35
Nut M10
Motor
2
1
69
70
Connecter pipe
Power cord
1
1
PART
ITEM
QTY
PART
ITEM
QTY
PARTS LIST
