OPERATION & ADJUSTMENT
5
1. There are two pressure gauges on the compressor:
The gauge on the right hand side show the current pressure in the
reservoir tank. The gauge on the left shows the outlet pressure, this
can be adjusted with the regulating valve.
2. The output pressure of compressed air can be adjusted by the
regulating valve. Pull out the regulating valve knob and turn it
clockwise to increase pressure.
3. When the running compressor needs to be stopped, set the pressure
switch to the o position.
4. As soon as the compressor has been turned o, release any
any compressed air in the discharge pipe by turning the regulator
knob fully anticlockwise. Failure to do this will result in damage to the
motor.
5. Once all compressed air has been released, remove any condensation
by unscrewing the drain cock.
