PARTS SUPPLIED IN PACKAGING
The following parts should be included with the display:
• Digital Depth Sounder Display
• White and Black Faces and Bezels (optional on some models, see
package for details)
• Thick Dash Extension Rod (optional on some models, see package for
details)
• Flush Mount Bracket and Hardware
• Display Power Harness and Waterproof Fuse Holder Attached to the Unit
OTICE
Refer to the manual supplied with the transducer for
transducer parts list.
If any items are missing or damaged, please contact our customer service
department.
SELECTING THE PROPER TRANSDUCER INSTALLATION
If you think that the included transducer is not suitable for your installation, return
to the place of purchase and exchange it for the correct transducer. You can
also visit our Customer Service Center at www.hawkeyelectronics.com to contact
us or to complete a transducer exchange request to exchange the transducer for
one that is specialized for your vessel. You may also visit
support.norcrossmarine.com to inquire about exchanging the transducer.
INSTALLING THE DISPLAY
Tools & Supplies Required for Installation
• Electric Drill
• 2” Hole Saw
• Wire Connectors Suitable for Connecting the Power Wire to Your Vessel
• Wire Cutting/Crimping Tool
• Marine Sealant/Caulk
STEP 1
Installing the Display
1. Find a location on the boat that will allow clear viewing of the display. Keep
in mind that the wires for the transducer and power must reach the mounting
location.
