1
2
3
x2
1. Slide the Mounting tool
E into the top
connector on the first profile.
2. Go back to pages 1011 and follow the
instructions to mount the wall bracket.
3. After mounting the wall bracket,
remove the two connectors as illustrated.
CONFIGURATION 3
Make sure to have finished
the first step with mounting
all connectors on the profiles
before going ahead with the
next step.
20 21
