Safety and Instructional Decals
Safety decals and instructions are easily visible to the operator and are located near any area of potential
danger. Replace any decal that is damaged or missing.
134-4908-A
1
4 5
2 3
134-4908
1. Warning—read the Operator’s Manual. 4. Thrown object hazard—keep bystanders away; shut off
the motor and wait for all moving parts to stop before
leaving the machine; pick up debris before mowing.
2. Cutting/dismemberment hazard of the hand, mower
blade—remove the key and read the Operator’s Manual
before performing maintenance.
5. Cutting/dismemberment hazard of the foot, mower
blade—do not mow up or down slopes; only mow across
slopes; look behind you when mowing in reverse.
3. Cutting/dismemberment hazard of the hand, mower
blade—remove the button and read the Operator’s
Manual before performing maintenance.
Motor Stop Motor Start
Moulded onto motor stop lever Moulded into button
Height of Cut Easy Wash™ Port
Moulded in top cover Located on top cover
Variable Speed Control
Power-Boost / Boost-Max
Power Control
Printed on control Printed on electric-starter
STOP
AUTO
MAX
134-4551-A
1
2
3
4
134-4551
1. Electric-Start Button & Electric Starter
2. Blade Control Bar - Engage
3. Electric-Start Button
4. Blade Control Bar - Disengage
